Loxit 8421

Single column electric mobile screen lift.

Heavy duty electric operation with reinforced welded brackets for displays and touch screens up to 86″.

Max screen weight 130kg.

Smooth electrical operation raises and lowers the screen by 600mm, allowing all users access to the display.

Suits VESA patterns up to 800mm wide x 440mm high.

For VESA mount patterns to 800mm x 600mm high use optional bracket set 8975.

Height from floor to centre of screen:
Lowered 1295mm
Raised 1895mm

Includes integrated 4 way power strip to power the screen and peripherals with just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety.

Switched, fused power inlet also includes 3 additional IEC outlets in addition to the 4 way power strip.

Cables are tidied away within the mount head for a professional and safe installation.

Ready assembled – simply screw the universal mount brackets onto the screen and hang on the trolley. Saves installation time and money.

For additional safety when being used in vulnerable environments such as with young children in nurseries, those in SEN environments or wheelchair users, add Hi-Lo® Anti-Crush Bar for Flat Screen 1.00m code 8973. The discrete pressure sensitive bar is adhered to the underside of the screen and cuts out power to the motor at the slightest contact.

Features
Very stable and durable single column electric trolley based lift for LED/LCD screens and displays.

Max screen weight 130kg max screen size 86″ diagonal.

Smooth, quiet electrical operation raises and lowers the screen by 600mm, allowing all users access to the display.

Height from floor to centre of screen 1295 – 1895mm.

Includes integrated 4 way power strip and 2 spare IEC outlets to power the screen and peripherals.

Just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety. Country specific cables available.

Ready assembled – simply screw the universal mount brackets onto the screen and hang on the trolley, saving installation time and therefore money.

Technical
600mm electric height adjustment.

Height from floor to centre of screen:
Lowered 1295mm
Raised 1895mm

Max screen size 86″

Max screen weight 130kg

Includes integrated 4 way UK power strip.

Includes 3m mains input cable.

Application

A mobile electric height adjustable display mount perfect for applications where touch screens, digital signage and video conferencing are used in presentations where there is a requirement for a a very high overall height of screen.

The 600mm electric travel screen wall mount is particularly suited for older children and adult users for example in older years primary school classes, higher and further education, board rooms and training rooms where the maximum height to the centre of the screen is approximately (depending on location of screen mount holes) 1895mm from the floor.

The higher starting point of the screen mount, coupled with the extra long 600mm travel creates a overall lift height which allows the screen to be raised 400mm higher than the Hi-Lo Mono 500 version.

The single column provides a stylish mount suitable for any environment.
