Kramer Electronics TP-580T

The TP−580T is a high−performance, HDBaseT twisted pair transmitter for HDMI, bidirectional RS−232 and IR signals. The TP−580T inputs HDMI, RS−232, and IR signals and converts them into an HDBaseT twisted pair signal that it transmits to a TP−580R receiver.

• Max. Data Rate - 10.2Gbps (3.4Gbps per graphic channel).

• HDTV Compatible.

• HDCP Compliance.

• HDBaseT™ Technology.

• HDMI Support - Deep Colour, x.v.Colour™, Lip Sync, HDMI Uncompressed Audio Channels, Dolby TrueHD, DTS−HD, CEC.

• 3D Pass-Through
.
• EDID PassThru - Passes EDID signals between the source and display.

• 2K & 4K Support.

• Bidirectional RS-232 & IR Interface. - Commands and data can flow in both directions via the RS−232 interface, allowing status requests and remote control of the destination unit.

• System Range - Up to 70m (230ft).

• Cable - For optimum range and performance using HDBaseT™, use Kramer's BC−HDKat6a cable. Note that the transmission range depends on the signal resolution, source and display used. The distance using non−Kramer CAT 6 cable may not reach these ranges.

• Indicators - Status LEDs for input, output, link and power.

• Compact DigiTOOLS® - 3 units can be rack mounted side−by−side in a 1U rack space with the optional RK−3T universal rack adapter.

Applications
• Projection systems in conference rooms, boardrooms, auditoriums, hotels and churches, production studios.

EAN # : 7291063051631
