ATEN VM1600A-AT-E

Aten VM1600A-AT-E

Product Key Features
• Connects any of 16 video sources to any of 16 displays in combination with ATEN Modular Matrix Solutions.
• Hot-pluggable: Modular Fan Design Power Module Easy integration of I/O boards.
• Optional redundant power supply for continuous operation.
• Multiple Control Methods – system management via front-panel pushbuttons, RS-232 control, and Ethernet connections (Web GUI).

Product Overview
The ATEN Modular Matrix Solution Series comprises the VM1600A/VM3200 Modular Matrix Switch in tandem with a range of hot-swappable I/O boards. The solution offers real-time control and advanced access to manage 16/32 video sources and 16/32 displays simultaneously, through modular I/O boards in a single chassis. Empowered by ATEN Seamless Switch™ technology, the VM1600A/VM3200 video matrix switches incorporate a speed-progressive video switching function and a unique scaler that integrates seamlessly with video wall systems.

The ATEN Modular Matrix Solution is easily expandable and ideal for large-scale A/V applications such as broadcasting stations, traffic and transportation-related control rooms, emergency service centers, and any application that requires customizable, high-speed A/V signal routing.

Boasting a sophisticated and intuitive design to deliver the best audio/visual distribution and control, reliability and lowest maintenance costs, the solution also incorporates ATEN’s Red Dot Award-winning GUI that can be accessed from anywhere over a network or the internet. Configuring a video wall or digital signage installation has never been easier.

Product Package Contents
• 1x VM1600A Modular Matrix Switch.
• 1x Power Cord.
• 1x Terminal Block connector.
• 1x Fan Module (pluggable).
• 1x Power Module (pluggable).
• 1x User Instructions.

More Product Key Features
• Connects any of 16 video sources to any of 16 displays in combination with ATEN Modular Matrix I/O Boards
• Multiple means for system configuration including front-panel pushbuttons, RS-232/422/485 control, and Ethernet connections for web GUI or Telnet
• View and control via ATEN Video Matrix Control App in a swift and agile way
• 4K resolutions –up to UHD (3840 x 2160) and DCI (4096 x 2160) with refresh rates of 30 Hz (4:4:4) and 60 Hz (4:2:0)*
• Scaler –features a (4K) video scaling function to convert input resolutions to the display’s native resolutions*
• Seamless Switch™ –features close-to-zero second switching for continuous video streams, real-time switching, and stable signal transmissions*
• Video wall –allows you to create custom video wall layouts via intuitive web GUI*
• Calendar-based scheduling – allows profile playing based on the pre-set schedule and RTC
• EDID Expert –selects optimum EDID settings for smooth power-up, high-quality display, and use of the best resolutions across different screens
• Audio-enabled –HDMI audio can be extracted and stereo audio can be embedded*
• Bi-directional RS-232 channel – allows you to control the connected serial devices simultaneously through the web GUI
• Supports redundant power module for higher reliability
• Hot-swappable design for I/O boards, fan module, and power supplies for easy maintenance and higher reliability
• Optional redundant power supply –ensures reliability for mission-critical applications
• Long-Reach mode up to 1080p@150m – enables extended AV transmission using the HDBaseT™ Input/Output board with ATEN • HDBaseT™ Class A Video Extenders
• HDCP 2.2 Compatible*
• HDMI: 3D, Deep Color, 4K*
• Consumer Electronics Control (CEC) supported*
• Rack mountable (6U design)
Note:
1. The availability of the features with “*”depends on which I/O board is inserted.
2. When Seamless Switch™ is enabled, 3D, Deep Color, or interlace (i.e., 1080i) formats will not be supported. To use these formats, make sure to disable Seamless Switch™.
3. Videos may not display within range when Seamless Switch™ or Video Wall is enabled, in which case please adjust the display settings on your device.

Product Specifications
Board Output
• 4 x Slot.

Board Input
• 4 x Slot.

Video Input
• Interfaces: Depends on which I/O board is inserted.
• Max. Data Rate: 15.2 Gbps (3.8Gbps per Lane).

Audio
• Input: Depends on which Input board is inserted.
• Output: Depends on which Output board is inserted.

Control
• RS-232: Connector: 1 x DB-9 Female (Black), Serial Control Pin Configurations:, Pin2 = Tx, Pin 3=Rx, Pin 5= Gnd.
Baud Rate and Protocol:, Baud Rate:19200, Data Bits:8, Stop Bits:1, Parity: No, Flow Control: No.
• RS-485/RS-422: Connector: 1 x Captive Screw Connector, 5 Pole.
• Ethernet: Connector: 1 x RJ-45 Female.

EDID Settings
• EDID Mode: Default / Port1 / Remix / Customized (EDID Wizard support).

Connectors
• Power: 1 x 3-Prong AC Socket.

Power
• Maximum Input Power Rating: 100-240 VAC; 50/60Hz; 3/6 A.

Power Consumption
• AC110V:460W:166BTU.
• AC220V:460W:156BTU.

Fan
• Airflow: 55.2 cfm.
• Operating Voltage: 10.2 - 12VDC.
• Operating Temp: -10 - 60°C.

Environmental
• Operating Temperature: 0 - 40°C.
• Storage Temperature: -20 - 60°C.
• Humidity: 0 - 80% RH, Non-Condensing.

Physical Properties
• Housing: Metal.
• Weight: 15.11 kg ( 33.28 lb ).
• Dimensions (L x W x H): 48.20 x 46.66 x 26.59 cm, (18.98 x 18.37 x 10.47 in.).
• Rack Height (U Spaces): 6U.

Carton Lot
• 1 pc.

Note
• For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.

EAN # : 4719264646287
