ZeeVee ZUHD60-2EMP

ZyPerUHD60 Encoder triple Input dual LAN

System Description
The ZyPerUHD60 platform allows for the easy distribution and switching of ultra high definition compressed video, audio, and other data signals using ZyPerUHD60 encoder and decoder units with off-the-shelf 1Gb Ethernet switches.

Send compressed video up to 4K, audio, and control over ethernet
ZyPerUHD60 delivers stunning pixel for pixel reproduction of compressed 1080p HD and full 4k@60 UHD resolution content directly over a standard 1Gb ethernet network. ZyPerUHD60 eliminates the need to have a separate AV network or equipment for video and other AV content.

Change sources and content instantly without programming ZyPerUHD60
IP based architecture enables you to quickly switch from one source to another with minimal loss of frames - even at 4K resolutions.

Create and manage video walls
ZyPerUHD60 can be used on multiple screens to create a video wall up to a 15x15 configuration.
The unit automatically scales and adjusts HD source content to create a compelling wall without any extra hardware or software. You can even mix scaled images with stand-alone screens.

ZyPerUHD60 Features:
• Dual HDMI and Single USB-C Video Inputs (With HDMI loopout)

• JPEG 2000 compressed 4K video, audio, and control using off-the-shelf 1Gb Ethernet switches

• Support for both analog and digital audio

• 4K@60Hz, 4:4:4 support

• ZyPerMP (Management Platform) with software GUI allows simple set up and control of ZyPerUHD60

• Power over Ethernet support (PoE)

• Ultra low latency

• Supports HDR

• Video Wall support up to 15x15

• Video Rotation support (90, 180, 270)

• Source and display control (RS232, IR, USB)

• HDCP 2.3 compliant

• 802.1x support

• Dante Embedded option with dedicated LAN Port

• Wallplate Encoder option

• Both Dual and Single Ethernet port ZyPerUHD60 versions available

ZyPerUHD60, 3x1 Switching Encoder (Dual HDMI and USB-C) with phoenix connector for analog audio in/out, with IP streaming via Gbit/copper. Supports HDMI 2.0a capable of up to 4KP60 4:4:4 with embedded audio and HDCP 2.3 encryption, USB, IR, RS-232 (via phoenix), HDMI passthrough, and Dual 1G LAN ports (1 supporting POE). Includes IR pigtail and wall mount brackets. Requires ZyPerUHD60 Decoder. Cables not included. 20V supply available separately to supply charging over USB-C port. Includes integrated ZyPer Management Platform running on a dedicated processor. Power supply sold separately.
