VP-2421 Power Amplifier
VP-2421 (420 W-by-1 channel)
Power Amplifier uses the VP-200VX or VP-200VX-BGM Power Amplifier Input Module per channel.
• Power Source 28V DC (operating range: 19 - 44V DC) M4 screw terminal, distance between barriers: 12mm
• Current Consumption (EN60065) 7.6A
• Rated Output Power 420W
• Output Voltage/Impedance 100V/24 Ω, 70V/12 Ω, 50V/6 Ω
(selectable by the internal wiring change)
• Number of channels 1
• Input Specified by input module VP-200VX or VP-200VX-BGM
• Number of Module slots 4, usable module: VP-200VX or VP-200VX-BGM
• Output Power amplifier output (speaker line): M3.5 screw terminal, distance between barriers: 8.8mm
• Frequency response 40 - 16,000Hz, ±3dB (at 1/3 rated output)
• Distortion Under 1% (at rated output, 1kHz)
• S/N Ratio Over 80dB
• Panel Indicator Channel power indicator: 1 channel, dual colour LED Overheat indicator: Yellow LED
• Operating temperature 0ºC to +40ºC
• Finish Panel: Surface-treated steel plate, black, 30% gloss, paint
• Dimensions 482 (W) x 88.4 (H) x 340.5 (D)mm
• Weight 9.5kg
