TOA CS-64BS Horn Speaker

Mfr. Part #: CS-64BS Our Part #: TOACS64BS
Your Price:  N/A
Qty. Login to see stock. Login to buy

Constant directivity horn improves directivity characteristics and ensures uniform and clear sound dispersion. Certified according EN54-24 for voice alarm systems.
Lightweight ABS resin enclosure that is mechanically strong and resistant to impact.
Weatherproof polyurethane resin paint permits the speaker to stand up to many years of outdoor installation.

• Rated Input 6 W
• Rated Impedance 100 V line : 1.7 kΩ (6 W), 3.3 kΩ (3 W), 10 kΩ (1 W)
• 70 V line : 830 Ω(6 W), 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W)
• Sound Pressure Level 96 dB (1 W, 1 m) (330Hz - 3.3kHz, pink noise)
• Frequency Response 130 - 13,000 Hz
• Speaker Component 12 cm cone - type dynamic speaker (treated for splash proof)
• Coverage Angle Horizontal and Vertical 360° (500Hz), 210° (1kHz), 85° (2kHz), 45° (4kHz)
• Finish Horn, cover : ABS resin, off - white, paint
• Bracket : Stainless steel
• Net : Surface treated steel plate, dark-gray, powder coating
• Screw : Stainless steel

Features
TypeProjection
Single/ PairSingle
Dimensions W/O Stand (W x H x D)233 x 224 x 249 mm
Weight1.7 Kg
