Sonnet Echo III Rackmount
|
Qty. | Login to see stock. | Login to buy |
Echo III RM 3-Slot TB3 - PCIe Card Expansion System
3-slot rackmount Thunderbolt 3 to PCIe card expansion system
Adds Connectivity & Capabilities
Connects up to three high-performance non-GPU PCIe cards via a Thunderbolt 3 cable to your computer lacking expansion slots.
Pro Tools | HDX Compatible(1)
HDX compatibility mode enables use of up to three Pro Tools | HDX PCIe cards with no additional parts needed.
Broad PCIe Card Compatibility
Every Thunderbolt 3 compatible, non-GPU card supported regardless of length or height.
Three PCIe 3.0 Slots(1)
One x16 plus two x8 slots support three full-height, single-width cards, or one double-width card plus one single-width card.
Pro Power
Integrated 400W power supply with 75W auxiliary power. Saves energy by powering on/off automatically with the computer.
Remarkably Quiet
Dual temperature-controlled, variable-speed Noctua fans rated at 17dBA automatically and quietly cool the cards.
40Gbps Thunderbolt 3 Interface
Offers 2750 MB/s of PCIe bandwidth for the installed cards(1).
Two Thunderbolt 3 Ports
One port connects to computer; second port supports daisy-chaining of up to five additional Thunderbolt peripheral devices.
Rugged 2U Steel Rackmount Housing + Optional Expansion Space
Provides robust and secure protection in server and DIT racks; space for optional future expansion.
| Features | |
|---|---|
| Type | DuoModo Expansion Systems |
| Product Description | ||
|---|---|---|
|
