SIGNET VL1B1 Loop amplifier

12V Induction Loop amplifier Kit, 1.2m2 (using the TX2 pre-formed loop) output, -27dB stereo unbalanced input, 1 year warranty

The amplifier includes two 3.5mm jack inputs (microphone and line), both with their own level controls, and a metal compensation feature which can be used to offset the frequency problems associated with running an induction loop close to metal. Two kitted versions are available. The VL1/B1 12V kit includes a VL1 amplifier, fused cigarette lighter adaptor, a pre-formed loop capable of generating a loop listening field of 1.2m2 (typically positioned in a vehicle’s roof lining or under a seat) and a microphone. A 24V version of the kit (the VL1/B2) is also available.
Measuring just 120mm wide, 31mm high and 60mm deep, the VL1 is ideal for dashboard mounting. It includes three indicators - Peak, Limit and Power On – and meets or exceeds the requirements of BS7594 and EN60118-4 when correctly installed.

VL1/B1 12V kit includes:-
1 x VL1 amplifier
1 x TX2 pre-formed loop
1 x AMT microphone
1 x AL8 fused cigarette lighter power adaptor
1 x ‘AFILS’ fitted sticker

Need help determining which SigNET induction loop amplifier and cable to use to create a BS7594 (2011) compliant AFILS installation? Click HERE to use SigNET’s new audio-frequency induction loop calculator.
