Panasonic TY-VK55LV2
Product Details
TY-VK55LV2 magnetic mounting system for 55" video walls dramatically reduces installation time, labor cost and eliminates panel-surface alignment inconsistencies.
Product Specifications
• Weight: Approx. 46.3 lbs (21.0 kg).
• Dimensions (W x H x D): 47.8" x 27" x 7.2" (1215 x 686 x 184 mm) (Stored.), 47.8" x 27" x 15.1" (1215 x 686 x 384 mm) (pulls out).
• Accessories:Installation Mount (1), Mount brackets (2), Surface alignment magnets (4), -Frame linking screws (M6 x 70) (4), - nuts (M6) (4), -flat washers (4), - spring washers (4), - Main unit fixing screws (2), - Mount bracket and Surface alignment magnets screw (M6 x 16 (12), - Surface alignment magnets screw (M4 x 16) (8), - Hexagonal wrent (included tool) (1).
• Carton Dimensions (W x H x D): 52.5" x 8.3" x 30.7" (1334 x 211 x 779 mm).
• Gross weight: Approx. 68.3 lbs (31 kg).
• Applicable display: 55" LFV, VF1, VF2 Video Walls.
Compatible Products
TH-55LFV9U 55" Class Video Wall Display - TH-55LFV9.
