Netgear AV MS510TXPP-100EUS

Netgear MS510TXPP-100EUS

Product Overview
Plenty of Headroom With 1G, 2.5G, 5G and Even 10G!
Businesses need to be ready for future expansion: with incoming new multispeed devices, their wired network needs to expand its reach and scope to support speeds greater than 1 Gigabit. The IEEE 802.3bz standard paved the way for new 2.5 Gigabit and 5 Gigabit speeds in addition to legacy 1 Gigabit and 10 Gigabit per second. New servers, workstations, storage devices, and motherboards are coming with 802.3bz (NBASE-T) Multi-Gigabit Ethernet for 2.5X to 5X faster speeds up to 100 meters (323 feet) on legacy Cat5E / Cat6 cables.

That is why NETGEAR launched its new 8-Port Multi-Gigabit Smart Managed Pro Switches with 10G Copper/Fiber Uplinks. Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the MS510TX and MS510TXPP give the exact speed required, with no downgrade. Also, the new NETGEAR Multi-speed switch ports can connect regular CAT5e Ethernet cables, without the need to upgrade to CAT6 wiring, therefore reducing wiring costs and hassle.

Access, Aggregation or Collapsed Core
You can now have your PCs, printers and routers/firewalls connected at 1G and aggregate Multi-Gigabit Ethernet new devices on the same switch, all line-rate. 10G copper and fiber ports are ready for local servers and storage, or high-speed aggregation to your network core.

Multi-Gigabit for Future-Proof Deployments
With or without PoE, the switches provide two Multi-Gigabit RJ-45 ports that support 5G, 2.5G, and 1G; another two Multi-Gigabit RJ-45 ports that support 2.5G and 1G; four 1G RJ-45 ports; one dedicated 10G RJ-45 uplink port (which also supports 5G, 2.5G and 1G); and one dedicated SFP+ fiber uplink port that supports 10G and 1G.

Comprehensive L2+/Layer 3 Lite Features
NETGEAR Smart Managed Pro Switches offer powerful L2+ and Layer 3 Lite features, enhanced performance and usability. They are purposely designed for converged networks where voice, video, data are all carried on a single network platform. These switches are optimized for network efficiency, operational cost savings, and ease of management. Advanced features such as IPv4/IPv6 Layer 3 static routing, DiffServ QoS, LACP link aggregation and Spanning Tree will satisfy even the most advanced small business networks.

Smart IT, Not Big IT
No need for an IT expert or a complicated user manual, just configure your network with the user-friendly NETGEAR Smart Managed Pro Web browser-based management GUI. The MS510TX and MS510TXPP are backed by NETGEAR ProSAFE Lifetime Limited Warranty and 24/7 support including lifetime chat.

Product Highlights
Hardware Features
Multi-Gigabit to Connect Any Type of Device to a Single Switch
• 2-port RJ-45 Multi-Gigabit Ethernet IEEE 802.3bz (NBASE-T) 100M/1G/2.5G/5G.
• 2-port RJ-45 Multi-Gigabit Ethernet IEEE 802.3bz (NBASE-T) 100M/1G/2.5G.
• 4-port RJ-45 Gigabit Ethernet 10M/100M/1G.
• 1-port RJ-45 10 Gigabit Ethernet Copper (100M/1G/2.5G/5G/10GBASE-T).
• 1-port SFP+ 10 Gigabit Ethernet Fiber (1G/10GBASE-X SFP+).

MS510TXPP
• 180W PoE budget available across 8 Gigabit and Multi-Gigabit PoE+ ports (802.3at).
• Fan-speed control with max 28.8dB at 25°C (77°F) ambient.

Non-Blocking Switching With 78Gbps Line Rate Fabric
• Get all the connectivity you want to your devices across all 10 ports of Gigabit, Multi-Gigabit and 10 Gigabit Ethernet, without congestion and in full duplex mode.

2-Port 10G Uplinks (One Copper Port and One Fiber SFP+)
• Perfect for local 10G server or for uplink and aggregation to your network core.

Software Features
Layer 3 Static Routing With 32 Routes (IPv4 and IPv6)
• Offloads your distribution or core layer routers with local interVLAN routing directly at the edge of your network.

Easy-to-Use Web Browser-Based Management GUI
• No need for an IT expert or a complicated user manual, just configure your network with the user-friendly NETGEAR Smart Managed Pro Web GUI.

Configurable L2 Network Features (VLANs, Rapid Spanning Tree, IGMP Snooping and Querier, IGMP Fast Leave…)
• Intuitive Web management streamlines initial configuration for rapid onboarding at the access layer of your network.

Advanced Per Port PoE Controls For Remote Power Management of PoE Connected Devices Including Operation Scheduling
• Simplifies management of Wireless APs, IP security cameras, LED lighting, secure access door locks, IoT devices…

Advanced Smart Switching Features (IPv4/IPv6 Layer 3 Static Routing, DiffServ QoS policies, LACP Link Aggregation, Broadcast Control, Denial of Service Protection
• Will satisfy even the most advanced small and medium organizations.

Key Features
Traffic Management
• Auto Negotiation of speed and duplex modes.
• IEEE 802.3x Flow Control.
• Dynamic MAC address management.
• IEEE 802.1Q-based VLAN.
• Auto Voice VLAN.
• Auto Video VLAN.
• VLAN routing.
• QoS based on WRR, strict priority, or both.
• Port-based and IEEE 801.2p-based QoS.
• TCP/UDP-based QoS.
• DiffServ.
• IPv4 and IPv6-based QoS.
• DSCP Support.
• Rate Limiting (ingress, or egress).
• Link Aggregation and LACP.

Security
• MAC lockdown.
• MAC lockdown by number of MACs.
• IEEE 802.1x port authentication - EAP.
• Dynamic VLAN Assignment.
• Guest VLAN.
• TACACS+.
• 3 HTTPS /SSL versions.
• TLS session.
• Trusted MAC.
• IPv4, L4-based Access Control List (ACL).
• IPv6-based ACL.

Multicast Efficiency
• IGMP snooping, v1, v2 and v3.
• IGMP Snooping querier.
• Blocking of unknown multicast traffic.
• MLD snooping.

Spanning Tree, Routing and Stacking
• IEEE 802.1D, IEEE 802.1w RSTP and MSTP.
• Option to enable/disable BPDU flooding when STP is disabled.
• IPv4 / IPv6 Static routing with 32 static routes each.
• Hosted ARP table size of 512.

Reliability, Performance and Troubleshooting
• Port mirroring both on ingress and egress traffic.
• Jumbo frame support.
• Broadcast Storm control.
• Cable diagnostics.
• Loop Detection.
• DoS Prevention.
• IEEE 802.1ab LLDP.
• LLDP-MED.
• Dual Image.
• SNTP.
• Option to enable/disable the flooding of EAPOL when 802.1x is disabled.
• Protected ports.
• DNS client.
• DHCP client.
• DHCP snooping.
• Ping and traceroute client.
• Energy Efficient Ethernet (IEEE 802.3az) compliant.

Switch Management
• Web browser-based management GUI.
• Smart Control Center Software for multi-switch management.
• IP Access List.
• IPv6 Management.
• Configurable Management VLAN.
• SNMP v1/v2c and v3.
• Standard MIBs (RFC1213, RFC1643, and RFC1493).
• RMON group 1, 2, 3, 9.
• Firmware Upgrade through Smart Control Center (TFTP).
• Firmware download (to switch) and upload (to server) through TFTP/HTTP.
• Configuration and Image Upload (to PC) through HTTP.
• Configuration Download (to Switch) thru TFTP/HTTP and upload (to server).
• Memory & FLASH log.
• Syslog (server).
• System password protection.

NETGEAR Warranty
• This product is backed by a NETGEAR ProSAFE® Limited Lifetime Hardware Warranty.
• Lifetime Next Business Day Hardware Replacement. Click here for coverage, availability and terms and conditions.
• ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts.
• ProSUPPORT Lifetime 24x7 Advanced Technical Support via chat.
