Middle Atlantic BGR4127

Why is BGR the #1 AV Enclosure? The BGR is designed to hold 20% more weight but be lighter than its predecessors. It offers more space efficiency for equipment mounting and cable management with Lever Lock™. It has options designed for system future proofing without disturbing the existing system. BGR is designed for today and tomorrow’s AV applications and with multiple form factors it supports multi-rack systems, single rack systems or a mobile systems.

• The 23” width gives you extra room in “no-man’s land” for front-to-back cable management and for mounting small devices on • Lever Lock™ freeing up valuable rackspace.
• Breakthrough design provides high strength without extra weight
• UL 1678, Seismic and OSHPD OPM Certified
• Wide open top and bottom offer many cabling and cooling options
• Accepts extender bay to add 3” of useable depth to the front or rear of the enclosure
• Accepts brush grommet rear door kit for a large cable passage without fishing
• Pre-threaded ganging holes allow ganging while enclosure is fully loaded
• Standard front and rear adjustable 10-32 threaded rackrail with numbered spaces
• Includes standard vented rear door that accepts optional fans

GENERAL INFO

Gangable: Yes
Finish: Black Powder Coat
UL Standards Tested: UL1678

LISTING AGENCIES/THIRD PARTY CERTIFICATIONS

ASCE: 7-10
RoHS: Yes
Greenguard: Yes
UL Listing No: E173107

DIMENSIONS

Usable Depth: 24.4
Usable Height: 71.875
Panel Width: 19
Depth (US): 27
Height (US): 75.875
Width (US): 23
Rack Units: 41

TECHNICAL INFORMATION

Rackrail Type: 10-32
Seismic Load Capacity: 1175
UL Load Capacity: 3000
Material: Steel
Mounting: Horizontal
Seismic Rating: Yes

Please Note - RACKS DO NOT COME WITH SCREWS, THESE WILL NEED TO BE ADDED SEPARATELY
