MAG Theatron M12-L
|
Qty. | Login to see stock. | Login to buy |
12" Home Screen Cinema Speaker - Left
Left Main Speaker
M12-L is a left speaker for the MAG Theatron main screen array. It is based on a long-excursion woofer and an HF driver with extremely low distortion. With horn coverage being horizontally symmetrical, M-12L is matched perfectly with M12-C and M12-R.
M12 series represents a whole new way to deliver sound into a home theater. Versions designed for left, right and center channels have the optimal coverage to put the sound right where it belongs.
M12-L and M12-R have their sound axis panned to the left and right respectively, allowing to aim the sound right to the listening position without rotating the speaker.
Every M12 system is equipped with a powerful 12” long-excursion woofer and a precision HF driver with extremely low levels of distortion.
Technical Data
• Frequency response: (±3 dB) 50 Hz – 20 kHz
• Frequency range - (-10 dB) 41 Hz – 22 kHz
• Max continuous SPL, dB 121.5
• Sensitivity (1W/1m, half-space), dB 97
• High-frequency driver : 1-inch (1.75 inch voice coil) titanium dome
• Low/Mid frequency woofer : 12-inch (2.5 inch voice coil)
• Coverage :90° H × 50° V, Coverage Control HF horn horizontal axis panned 15° left
• Nominal impedance, Ohm :4
• Power rating, W : 300
• Connectors : Phoenix terminals
• Dimension (W x H x D), mm / in : 565 × 840 × 250 / 22.24” × 33.01” × 9.84”
• Net weight, kg / lbs 32.2 / 71
| Features | |
|---|---|
| Application | Cinema |
| Speaker Type | LCR Surround Speaker |
| Speaker Series | M12 |
| Speaker Size | 12 " |
| Bass/Mid Unit | 12" Reinforced Celluloid Cone |
| Tweeter | 1" Titanium Dome |
| Frequency Response | 50Hz-20kHz |
| Impedance | 4 Ohms |
| Sensitivity | 97 dB |
| Recommended Amplifier Power | 300 Watts |
| Cut-Out-Size (W x H) | 565 x 840 mm |
| Colour | Black |
| Warranty | 6 Year |
