Loxit 8426

Single column floor mounted electric screen lift.

Heavy duty electric operation with reinforced welded brackets for displays and touch screens up to 86″.

Max screen weight 130kg.

Smooth electrical operation raises and lowers the screen by 600mm, allowing all users access to the display.

Suits VESA patterns up to 800mm wide x 440mm high.

For VESA mount patterns to 800mm x 600mm high use optional bracket set 8975.

Height from floor to centre of screen:
Lowered 1140mm
Raised 1740mm

Base includes 4 x 11mm holes for 10mm fixings into the floor if required.

Floor standing display lift includes integrated 4 way power strip to power the screen and peripherals with just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety.

Switched, fused power inlet also includes 3 additional IEC outlets in addition to the 4 way power strip.

Cables are tidied away within the mount head and then covered with the ventilated grille for a professional installation.

For additional safety when being used in vulnerable environments such as with young children in nurseries, those in SEN environments or wheelchair users, add Hi-Lo® Anti-Crush Bar for Flat Screen 1.00m code 8973. The discrete pressure sensitive bar is adhered to the underside of the screen and cuts out power to the motor at the slightest contact.

Features
Very stable and durable single column electric free standing lift for LED/LCD screens and displays.

Max screen weight 130kg max screen size 86″ diagonal.

Smooth electrical operation raises and lowers the screen by 600mm, allowing all users access to the display.

Height from floor to centre of screen 1140 – 1740mm.

Includes integrated 4 way power strip and 2 spare IEC outlets to power the screen and peripherals.

Just one cable to the mains socket.

Includes 3m hi-vis mains input cable for additional safety. Country specific cables available.

Technical
600mm electric height adjustment.

Height from floor to centre of screen:
Lowered 1140mm
Raised 1740mm

Max screen size 84″

Max screen weight 130kg

Includes integrated 4 way UK power strip.

Includes 3m mains input cable.

Application
Perfect for free standing applications where a wall is not strong enough to take the weight of the screen and mount.

Height adjustment is perfect for touch screen and video conferencing applications where screen height is important.

The floor standing version is used where a free standing installation is required.

The smooth electric height adjustment positions the screen perfectly with 600mm of travel.

Includes 4 holes in the base to allow for 10mm fixings into the floor if required.
