Lindy 70618

2ch XLR Audio to Dante® Encoder

Bring Analogue XLR Audio into Dante® Networks
The Lindy 2ch XLR Audio to Dante® Encoder provides a simple and reliable way to integrate analogue XLR audio sources into Dante® networked audio systems, making it ideal for professional AV, live sound, broadcast and installed audio environments.

Seamless Two Channel XLR Conversion for Dante® Workflows
Designed to bridge traditional analogue audio equipment with modern digital audio networks, this compact encoder converts two XLR input channels into low latency, uncompressed Dante® audio. With support for PoE, USB-C power and Dante® Controller software, it offers a flexible and scalable solution for integrating mixers, DSPs, DI boxes, compressors and wireless receivers into professional networked audio systems.

2 channel XLR audio input
Captures high quality analogue audio for Dante® network distribution.

Dante® and AES67 support
Enables integration into scalable professional audio networks.

USB-C or PoE powered
Flexible power options simplify installation and deployment.

Compact metal housing
Suitable for field use, rack setups and fixed AV installations.

The 2ch XLR Audio to Dante® Encoder is ideal for connecting analogue audio sources such as mixers, DSPs, DI boxes, compressors and wireless microphone receivers to Dante® enabled networks. It is well suited to live sound systems, broadcast environments, corporate AV installations, education spaces, houses of worship and venues where reliable long-distance audio distribution is required.

The encoder supports Dante® and AES67 protocols with 24-bit audio and sample rates of 44.1, 48, 88.2 and 96kHz. It provides two XLR female inputs, one RJ45 network output and supports transmission distances up to 100m (328.08ft) over standard network infrastructure.

Power can be supplied via USB-C or 802.3af PoE, with maximum power consumption of 2.35W. The compact metal housing measures 127 x 53 x 26mm and is designed for practical use in portable, rack-mounted and fixed installation environments.

The encoder is supplied with mounting ears and screws, a user manual and is backed by a 3-year warranty.

Features:
• Converts 2 channel analogue XLR audio into Dante® network audio, providing seamless integration of traditional audio equipment within modern IP-based AV and professional audio systems
• Dual XLR input channels support high quality audio capture with reliable signal integrity, making the encoder suitable for broadcast, live sound, installed AV and studio environments
• Ideal for integrating mixers, DSPs, DI boxes, compressors and wireless microphone receivers into Dante® and AES67 networked audio infrastructures
• Supports both USB-C and 802.3af PoE powering, simplifying installation in racks, AV cabinets, portable production systems and fixed professional AV deployments
• 3 year warranty

EAN # : 4002888706186
