Lindy 47140

Mfr. Part #: 47140 Our Part #: LINDY47140
Your Price:  N/A
Qty. Login to see stock. Login to buy

20m Cat.6A S/FTP LSZH Network Cable, Grey

Product Details
• Twisted Pair Patch Cable with RJ45 connectors.
• Cat.6A S/FTP PIMF, LSZH.
• Integrated snagless connector for latch protection.
• Gold plated pins for better conductivity and elimination of signal loss.
• 10 year warranty.

Cat.6A S/FTP network cable with support for bandwidth up to 500MHz and features a snagless design with gold plated contacts for ethernet standards up to 10 GBase-T.

Cat.6A cable, shielded with braid as overall shield and foil shield for the individual wire pairs (S/FTP). Cat.6A cables meet the requirements of 10 Gigabit Ethernet (10GBaseT) with an operating frequency of up to 500MHz. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.

The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.

The halogen-free sheath material of the LSZH cable makes the product suitable for use in public spaces with its low smoke emission and elimination of toxic halogen emissions.

Product Technical Information
Cable Construction
Length: 20m (65.62ft).
Colour: Grey.
Type: Cat.6A.
Jacket Diameter: 6.0mm (0.24in).
Jacket Material: LSZH.
Conductor Material: Copper.
Conductor Gauge: 27AWG.
Shielding: Aluminium Braid.

Specifications
Supported Bandwidth: 500MHz.
Nominal Attenuation: 49.3dB/100m @ 500MHz.
Minimum Bend Radius: 72mm (2.84in).
Operating Temperature: -10°C - 60°C (14F - 140°F).
Storage Temperature: -20°C - 75°C (-4F - 167°F).

Miscellaneous
Packaging Type: Polybag.
Warranty (Years): 10.
Certificated: RoHS, REACH, UL, California Proposition 65.

Purchasing Information
No.: 47140.
EAN: 4002888471404.

EAN # : 4002888471404

Features
Product TypeCat6 Shielded/Cat6A & Cat7 Patch Cable
ColourGrey
Length20.0m
