Lindy 42683

30m Fibre Optic USB 3.0 Cable Type A Male

PRODUCT DETAILS

• 30m Active Optical (AOC) USB 3.0 Cable
• Supports transfer rates up to 5Gbps
• Low RFI/EMI for sensitive environments
• Plug & Play installation
• 2 year warranty

The Lindy Fibre Optic USB 3.0 Cable supports far longer distances than standard copper cables whilst retaining SuperSpeed transfer rates of up to 5Gbps.

A lighter and more flexible construction makes this cable simple to install with cable trays and through conduits, whilst low RFI/EMI ensures that the cable can be installed in the most sensitive of environments.

For added convenience the Fibre Optic USB 3.0 cable is supplied with a USB Micro-B cable and a power supply, which can be connected should additional power be required.

Please note: this product is not backwards compatible with USB 2.0 or USB 1.1.

Information about USB 3.0, 3.1 & 3.2

USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB Type C host interface.
USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5 Gbps.
USB 3.1 Gen 2 and USB 3.2 Gen 2 both support data transfer rates up to 10 Gbps.

• Data transfer up to 5Gbits/s
• Only supports USB 3.0 (not compatible with USB 2.0/1.1)
• Supplied with USB A / Micro-B cable and USB charging adapter to supply power
• Optical USB 3.0 cable supports greater distances compared to conventional copper wire and is totally immune from electrical interference.

• USB 3.0 Active Optical Cable (AOC), compliant with SuperSpeed USB electrical specifications
• 850nm Laser Optical Transmission Technology
• 90 Ohm impedance, low RFI/EMI for sensitive environment
• Interoperability between existing USB 3.0 hosts, hubs and devices
• Not backwards compatible with USB 2.0!
• Ultra-thin profile and long reach up to 100m
• Plug & Play
• Connectors: USB A male, USB A female
• Power through USB Charger 5V DC 2A and USB 2.0 A to Micro-B cable

Connectors

• Connector A: USB Type A Male
• Connector B: USB Type A Female
• Power: USB Micro-B Female
• Housing Material: Plastic
• Connector Plating: C2680
• Pin Construction: C2680+Nickel+Gold
• Pin Plating: Gold
• Dimensions (approx.) WxDxH:
• USB A Female: 20x78x12mm (0.79x3.07x0.47in)
• USB A Male: 16x65x8mm (0.63x2.56x0.31in)

Cable Construction

• Length: 30m (98.42ft)
• Standard: USB 3.1 Gen 1 / USB 3.0
• Colour: Orange
• Type: Round
• Jacket Diameter: 3mm (0.12in)
• Jacket Material: LSZH
• Conductor Material: -
• Conductor Gauge: -
• Shielding: Aluminium Foil + Tinplate

Specifications

• Supported Bandwidth: 5Gbps
• Nominal Attenuation: 2.5dBm/km
• Minimum Bend Radius: 37.5mm (1.48in)
• Maximum Tensile Load: 0.7GN/m²
• Operating Temperature: 0°C - 50°C (32°F - 122°F)
• Storage Temperature: -20°C - 70°C (-4°F - 158°F)
• Transmission Medium: Optical Fiber 50/125 Multimode Fiber
• Transmission Technology: 850nm Laser Optical

Miscellaneous

• Packaging Type: Carton Box
• Packaging Dimensions: 310x210x70mm (12.2x8.27x2.76in)
• Net Weight: 0.294 (0.65lb)
• Gross Weight: 0.651kg (1.44lb)
• Warranty (Years): 2
• Certificated: CE, FCC, RoHS & REACH

EAN # : 4002888426831
