Lindy 42679

The Lindy USB 2.0 Cat.5 Extender extends the distance between four USB peripheral devices and the computer up to distances of 60m using a single Cat.5e/6 or higher network cable.

The Extender is a two part hardware solution comprising a transmitter that connects directly to your computer and a receiver that connects to the USB device.

It is perfect for use with USB 2.0 devices such as storage devices, printers, scanners, mice and keyboards. The included power supply ensures secure and uninterrupted electricity supplies.

• Extends the distance of 4 USB 2.0 peripherals by up to 60m
• Connect devices using standard Cat.5e/6 or higher network cables (not included)
• Supports USB 2.0 High Speed transfer rates up to 480Mbps
• Plug & Play installation, OS independent
• 2 year warranty

Technical Information

Specifications
• USB Standard: USB 2.0
• Supported Bandwidth: 480Mbps
• Maximum Distance: 60m (196.85ft)
• Transmission Medium: Cat.5/5e/6 or higher network cable
• Chipset: LT-8311

Connectors
• Transmitter Input: USB Type A (Male)
• Transmitter Output: RJ45 (Female)
• Receiver Input: RJ45 (Female)
• Receiver Output: 4 x USB Type A (Female)
• Power: 3.5/1.35mm DC socket

Physical Properties
• Dimensions WxDxH: 52x60x23mm (2.05x2.36x0.91in)
• Housing Material: Plastic
• Net Weight: 0.08kg (0.18lb)
• Operating Temperature: -10°C - 60°C (14°F - 140°F)
• Storage Temperature: -20°C - 70°C (-4°F - 158°F)
• Humidity: 0 - 80% RH (non-condensing)
• Power Requirements: 5VDC 4A
• Colour: Black

Miscellaneous
• Packaging Type: Carton Box
• Packaging Dimensions: 170x140x70mm (6.69x5.91x2.76in)
• Gross Weight: 0.36kg (0.79lb)
• Warranty (Years): 2
• Certificated: CE, FCC, RoHS & REACH

Package contents
• Transmitter unit
• Receiver unit
• Multi-Country Power Supply (EU, UK, US & AUS)
• Lindy Manual

EAN # : 4002888426794
