Lindy 41062

DisplayPort Male 1.2 to HDMI Female 18G with HDR Active Converter

The Lindy DisplayPort to HDMI with HDR Converter is a high performance solution that allows a DisplayPort source device to be connected to a HDMI display or projector.

It supports full 4K Ultra HD resolutions up to 3840x2160@60Hz 4:4:4 8bit, and with additional support for High Dynamic Range, 4K content can be viewed with crystal clear clarity, enhanced contrast and more lifelike colour, perfect for creating eye catching digital signage, engaging conference room displays or field based demonstrations and training.

Support for HDCP 1.4 and 2.2 also guarantees issue-free playback of a variety of 4K Ultra HD movies, TV shows and other 4K content as well as existing Full HD signals. Active conversion ensures compatibility with various graphics cards including AMD Eyefinity, NVIDIA surround and Intel Collage, great for an immersive gaming setup or a productive multi-screen working experience.

Please note: Windows 10 version 1903 is the minimum requirement for full HDR support

PRODUCT DETAILS

• Connects a DisplayPort source to an HDMI display
• Supports resolutions up to 4K@60Hz
• High Dynamic Range support for deeper blacks, brighter whites and a wider colour gamut
• Active chipset for enhanced compatibilty with various graphic cards
• 2 year warranty

TECHNICAL INFORMATION
Specifications

• AV Interface: DisplayPort to HDMI
• Interface Standard: DisplayPort 1.2, HDMI 2.0b
• Supported Bandwidth: 18Gbps
• Maximum Input Resolution: 3840x2160@60Hz 4:4:4 8Bit, 3840x2160@60Hz 4:2:2 10Bit
• Maximum Output Resolution: 3840x2160@60Hz 4:4:4 8Bit, 3840x2160@60Hz 4:2:2 10Bit
• Chipset: PS186
• HDCP Support: HDCP 2.2
• Supported Audio: Pass-through
• Separate Audio Ports: -
• Special Features: Supports HDR (High Dynamic Range)

Connectors

• Input: DisplayPort Male
• Output: HDMI Type A Male

Physical properties

• Dimensions (approx.) WxDxH:
• 20x37x10mm (0.79x1.46x0.39in)
• 22x42x12mm (0.87x1.65x0.47in)
• Cable Length: 180mm (7.09in)
• Housing Material: ABS
• Jacket Material: PVC
• Jacket Diameter: 5mm (0.2in)
• Minimum Bend Radius: 55mm (2.17in)
• Net Weight: 0.023kg (0.05lb)
• Operating Temperature: 0°C - 70°C (32°F - 158°F)
• Storage Temperature: -20°C - 70°C (-4°F - 158°F)
• Humidity: 0 - 90% RH (non-condensing)
• Colour: Black

Miscellaneous

• Packaging Type: Polybag
• Packaging Dimensions: 160x160x20mm (6.3x6.3x0.79in)
• Gross Weight: 0.031kg (0.07lb)
• Warranty (Years): 2
• Certificated: CE, FCC, RoHS & REACH, California Proposition 65

Package Contents

• DisplayPort 1.2 to HDMI 2.0 18G with HDR Active Converter

EAN # : 4002888410625
