Lindy 38336

2 Port HDMI 18G Bi-Directional Switch

• Switches between two source devices to one output, or one source device to two outputs
• Supports resolutions up to 4K 3840x2160 @60Hz
• Supports HDMI audio pass-through
• No external power supply required, for easy and discreet installation
• 2 year warranty

The Lindy HDMI 18G Bi-directional Switch allows the user to connect two 4K Ultra High Definition source devices such as Blu-Ray players or games consoles to a single 4K Ultra HD display or projector and easily switch between them at the push of a button. Alternatively, connect one 4K Ultra HD source can be connected to two 4K Ultra HD displays or projectors and switch between displays at the touch of a button.

With support for resolutions up to 4K 3840x2160 @60Hz, this switch ensures a superior visual experience within residential, education or conferencing installations.

The switch’s minimalistic design, with no external power requirement, allows for a clean, discreet installation.

Specifications

• AV Interface: HDMI
• Interface Standard: HDMI 2.0
• Supports Bandwidth: 18Gbps
• Maximum Resolution: 4096x2160@60Hz 4:4:4 8bit
• HDCP Support: Pass-through
• Supported Audio: Pass-through
• Separate Audio Ports: -
• IR Support: -
• CEC Support: Pass-through
• Serial Interface: -
• Special Features: Bi-Directional Capability

Connectors

• Input: 2 x HDMI Type A (Female) Bi-Directional
• Output: HDMI Type A (Female) Bi-Directional
• Control: -
• Power: Powered via HDMI interface

Physical Properties

• Dimensions (approx.) WxDxH: 49x52x20mm (1.93x2.05x0.79in)
• Housing Material: Metal
• Net Weight: 0.7kg (1.54lb)
• Operating Temperature: 0°C - 70°C (32°F - 158°F)
• Storage Temperature: -10°C - 80°C (14°F - 176°F)
• Humidity: 10% to 85% RH (no condensation)
• Power Requirements: -
• Colour: Black

Miscellaneous

• Packaging Type: Carton Box
• Packaging Dimensions: 63.5x80x28mm (2.5x3.15x1.1in)
• Gross Weight: 0.84kg (1.85lb)
• Warranty (Years): 2
• Certified: CE, UKCA, FCC, RoHS, REACH & California Proposition 65

Package Contents

• 2 Port HDMI 18G Bi-Directional Switch
• Lindy Manual

EAN # : 4002888383363
