Lindy 38321

Mfr. Part #: 38321 Our Part #: LINDY38321
Your Price:  N/A
Qty. Login to see stock. Login to buy

20m Fibre Optic Hybrid Micro-HDMI 18G Cable with Detachable HDMI & DVI Connectors, Black

Product Details
• Combines copper and fibre optic cable for a hybrid, long distance HDMI, Micro-HDMI & DVI connectivity solution.
• Supplied as a Micro-HDMI Male to Male cable, with detachable HDMI & DVI connectors.
• Supports HDMI 2.0 18G resolutions up to 4K@60Hz with additional support for HDR.
• Premium, metal connectors.
• 2 year warranty.

Lindy’s range of Fibre Optic Hybrid Micro-HDMI 2.0 18G Cables with detachable connectors are the professional solution for extending Micro-HDMI, HDMI & DVI signals over longer distances, with no requirement for additional adapters. Combining the flexibility and high EMI & RFI resistance of fibre optic cable with standard copper cabling, these hybrid cables are ideal for use in critical AV setups or commercial installations.

Supplied as a thin cable with a premium metal, narrow Micro-HDMI connector, this can be installed easily through conduit and other small spaces with no damage caused to the internal cable structure, while the detachable HDMI and DVI connectors can be added at the ends of the installation for connection to an even wider variety of displays and devices such as TVs, PCs or digital signage. This innovative design allows for a much wider range of connectivity solutions that can be customized freely by the user, including HDMI to DVI, HDMI to HDMI or DVI to a DVI display.

Supporting all the premium features that come with the HDMI 2.0 18G specification, these cables can deliver resolutions up to 4K at 60Hz, perfect for ensuring the best possible image quality in attention grabbing retail displays, immersive AV installations at events or a premium residential setup. HDR support ensures a much wider colour gamut, greater contrasts and an enhanced brightness to provide eye catching content even in outdoor or brightly lit scenarios.

Technical Information

Connectors
Connector A: Micro-HDMI Male
Connector B: Micro-HDMI Male
Housing Material: Zinc Alloy
Connector Plating: Gold Plated
Pin Construction: Gold-Plated Brass
Pin Plating: Gold Plated
Dimensions (approx.) WxDxH: Micro-HDMI Connector: 44.2x12.7x7.1mm (1.74x0.5x0.28in), HDMI Connector: 48.2x20x10mm (1.9x0.79x0.39in), DVI Connector: 43x40x14.5mm (1.69x1.57x0.57in)

Cable Construction
Length: 20m (65.62ft)
Standard: HDMI 2.0
Colour: Black
Type: Round
Jack Diameter: 6mm (0.24in)
Jack Material: PVC
Conductor Material: Gold Plated Copper
Conductor Gauge: 24AWG
Shielding: Aluminium Mylar

Specifications
Supported Bandwidth: 18Gbps
Maximum Resolution: 4096x2160@60Hz 4:4:4 8bit
Nominal Attenuation: -1dB~-2dB
Minimum Bend Radius: 60mm (2.36in)
Operating Temperature: 0°C - 50°C (32°F - 122°F)
Storage Temperature: -20°C - 85°C (-4°F - 185°F)

Miscellaneous
Packaging Type: Carton box
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH & California Proposition 65

Purchasing Information
No.: 38321
EAN: 4002888383219

EAN # : 4002888383219

Features
TypeHDMI Fibre/Optical Cables
Length20.0m
ColourBlack
PackagingCarton Box
AWG Size24
