Lindy 32120

HDMI / VGA / DVI EDID Recorder

The Lindy EDID Recorder is a useful solution to solving a variety of EDID compatibility issues that may occur when connecting mixed displays or using splitters, extenders or switches.

This recorder intelligently copies a connected HDMI , VGA or DVI displays EDID and stores it, to then be repeatedly used with Lindy’s range of EDID emulators (32104, 32121 and 32122), overwriting the emulator’s pre-set EDID to ensure seamless compatibility within the installation. The EDID recorder’s simple switch for copying EDID information allows for hassle free use for both professional and first time users.

• Stores EDID data to ensure maximum compatibility between a source and display
• Clones and stores EDID / DDC information from a HDMI, VGA or DVI display
• Overwrites pre-set EDID of emulators with stored EDID for time saving compatibility
• For use with HDMI (32104), VGA (32121) and DVI (32122) EDID Emulators
• 2 Year Warranty

Specification

• AV Interface: HDMI / VGA / DVI
• Interface Standard: HDMI 2.0
• Supported Bandwidth:
• HDMI: 18Gbps
• VGA: 4.95Gbps
• DVI: 9.9Gbps
• Maximum Resolution:
• HDMI: 3840x2160@60Hz 4:4:4 8bit
• VGA: 1920x1200@60Hz
• DVI: 2560x1600@60Hz
• Video EDID: -
• Audio EDID: -
• HDCP Support: -
• Special Features: -

Connectors

• Input: HDMI Type A (Female), VGA (Female), DVI-D (Female)
• Output: -
• Power: 3.5/1.35mm

EAN # : 4002888321204
