Kramer Electronics FC-69
|
Qty. | Login to see stock. | Login to buy |
The FC−69 is a high−performance 4K@60Hz (4:2:0) UHD, 4Kx2K HDMI audio embedder and de−embedder. The unit can embed analog audio to the HDMI output or de−embed audio from the HDMI input or from the HDMI output Audio Return Channel to S/PDIF and unbalanced stereo audio outputs simultaneously.
• Max. Resolution - 4K@60Hz (4:2:0) UHD, 4Kx2K.
• Maximum Data Rate - 8.91Gbps (2.97Gbps per data channel).
• HDTV Compatible.
• HDCP Compliant.
• HDMI Support - ARC and HDMI uncompressed audio channels, deep color, CEC.
• Audio Embedding - Even without an HDMI source.
• Audio de-Embedding - To unbalanced analog and S/PDIF, selectable from input or ARC.
• Kramer Equalization & re-Klocking™ Technology - Rebuilds the digital signal to travel longer distances.
• Sleep Mode - 5V on the output, following the input, allows the display to turn off when no video is being sent.
• Preconfigured Control Options - DIP−switches control locking/modifying EDID, HDCP, embedding/de−embedding and sleep mode functionality.
• Size - Compact DigiTOOLS® - 3 units can be rack mounted side-by-side in a 1U rack space with the optional RK-3T rack adapter.
EAN # : 7291063072513
