Kramer Electronics DA3-28-H
|
Qty. | Login to see stock. | Login to buy |
2:8 4K HDR HDMI DA
DA3−28−H is a premium 2x1:8 switcher and distribution amplifier for up to 4K HDR, video signals that comply with HDCP 2.2 content protection standard. The unit switches between one of two inputs HDMI or USB−C, equalizes and re−clocks the selected signal and distributes it to four identical outputs.
• Max. Resolution - 4K@60Hz (4:4:4).
• Intelligent EDID Handling - Use connected display EDID or default EDID, with EDID lock and RGB-force options, to ensure proper operation of HDMI source and display systems.
• Force RGB - When the display lacks YCbCr capabilities, the user can force native delivery of the RGB color format in HDMI content to improve picture quality.
• Selectable HDCP Authorization - Allows the user to control the appearance of an HDCP or non-HDCP input to the source to permit delivery of protection-free content, such as personal clips and charts, without HDCP encryption. HDCP protected content is not passed in non-HDCP mode.
• Sophisticated CEC mediator with flexible routing options.
• Analog audio output - de-embedded from the HDMI/USB-C input signal
• RS-232 port may be configured to control external devices
• Easy Installation - 1’ enclosure for over–ceiling mounting, or side by side rack mounting.
EAN # : 7291063100483
