Icron EL5363 HDMI & USB2 with UK Power supply 1920 x 1200 Single Cat5/6/7 KVM Extender

The EL5363 KVM Extender System features the latest and most robust HD video and USB extension technology from Icron Technologies. The EL5363 extends both HDMI and USB 2.0 up to 100m using a single Cat 5e/6/7 cable.

Product Key Features

The EL5363 KVM Extender lets you place an HDMI host up to 100 meters (330 feet) away from
the viewing area using a single Cat 5e/6/7 cable. The system supports full HD video and
USB 2.0, providing the ability to control keyboards, mice, flash drives, audio peripherals
and other USB 2.0 and 1.1 devices.

Key Features Include:
• Point-to-point video and USB extension up to 100m over a single CAT 5e/6/7 cable.
• Full uncompressed HD video: 4Kp30, 1080p and 1920x1200 resolutions.
• 3D.
• Deep Color.
• x.v. Color.
• Lip Sync Pass-through.
• CEC Pass-through.
• HDCP Pass-through.
• USB 2.0 throughput support up to 40Mbps.

Includes ExtremeUSB® Suite of Features:
• Transparent USB extension.
• True plug and play; no software drivers required.
• Works with all major operating systems: Windows®, macOS™ and Linux®.

Product Applications
• Medical Extensions.
• Interactive Digital Signage.
• Home Theater.
• Industrial Contro.

Product Specifications

Range
• Direct Connect: Up to 100m (330 ft) over a single CAT 5e/6/7 cable.

Video
• Resolution: High Definition 4Kp30, 1080p, 1920 x 1200.
• Color: 36-bit, Deep Color, and x.v. Color.
• Depth: 2D and 3D.
• Latency: Less than 1ms.

Speeds
• USB 2.0: Up to 40Mbps.
• USB 1.1: Up to 12Mbps.

LEX
• Video Connector: 1 x HDMI.
• USB Connector: 1 x USB Type B Receptacle.
• Link Connector: 1 x RJ45.
• Dimensions: 112mm x 175mm x 30mm (4.4" x 6.9" x 1.2").
• Enclosure Material: Silver Anodized Aluminum.
• Power Supply: 100-240V AC Input, 5V DC Output.

REX
• Video Connector: 1 x HDMI.
• USB Connectors: 3 x USB Type A Receptacles.
• Link Connector: 1 x RJ45.
• Dimensions: 112mm x 175mm x 30mm (4.4" x 6.9" x 1.2").
• Enclosure Material: Silver Anodized Aluminum.
• Available Current: 500mA for each USB port.
• Power Supply: 100-240V AC Input, 5V DC Output.

Environmental
• Operating Temperature: 0°C to 40°C (32°F to 104°F).
• Operating Humidity: 20% to 80% relative humidity, non-condensing.

Compliance
• EMC: FCC (Class A), CE (Class A), ICES-003.
• Environmental: RoHS2 (CE).

Support
• Warranty: 2-year.
