ICE Cable CONTROL YELLOW
Mfr. Part #: CONTROLYELLOW
Our Part #: ICECONTROLYELL
|
Qty. | Login to see stock. | Login to buy |
Control Yellow CresNet Automation Cable - 1000 Feet
• Component: 2C (1 Twisted Pair)
• Conductor: Stranded Bare Copper
• AWG 22
• Construction (±0.003mm) 7/0.254
• Stranded Diameter. (mm) 0.78
• Insulation: FOAM PE
• Nom. Thickness (mm) 0.50
• Insulation Diameter. (±0.05mm) 1.8
• Drain Wire (Stranded Tinned Copper) 7/0.20T
• Shield: Aluminum/Polyester
• Coverage (%) 125%
• Component B: 2C
• Conductor: Stranded Bare Copper
• AWG 18
• Construction (±0.005mm) 7/0.40
• Stranded Diameter. (mm) 1.22
• Insulation: SR-PVC
• Nom. Thickness (mm) 0.18
• Insulation Diameter. (±0.05mm) 1.6
• Component A & B cabled together
• Ripcord: 210Dx6 nylon thread
• Jacket: PVC
• Nom. Thickness (mm) 0.65
• Outer Diameter. (±0.10mm) 5.6
| Features | |
|---|---|
| Committed To Custom | Yes |
| Type | Lutron |
| Length | 305m |
| Colour | Yellow |
| Packaging | Box |
