• Capacity
1,000 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
• Form Factor
2.5 inch
• Interface
SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
• Dimension (WxHxD)
100 X 69.85 X 6.8 (mm)
• Weight
Apporx. 45.0g Weight
• Storage Memory
Samsung V-NAND 3bit MLC
• Controller
Samsung MKX Controller
• Cache Memory
Samsung 1 GB Low Power DDR4 SDRAM
Performance
• Sequential Read
Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration
• Sequential Write
Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
• Random Read (4 KB, QD32)
Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
• Random Write (4KB, QD32)
Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
• Random Read (4 KB, QD1)
Up to 13,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
• Random Write (4 KB, QD1)
Up to 36,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Environment
• Average Power Consumption (system level)
Average: 2.5 W *Maximum: 4.0 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
• Power consumption (Idle)
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
• Allowable Voltage
5V ± 5% Allowable voltage
• Reliability (MTBF)
1.5 Million Hours Reliability (MTBF)
• Operating Temperature
0 - 70 ℃ Operating Temperature
• Shock
1,500 G & 0.5 ms (Half sine)
