Cloud Electronics MA60

MA60 Mixer/Amplifier
The MA60 is an exciting new development from Cloud Electronics, combining for the first time the proven versatility of Cloud mixer-amplifiers in a single compact (2U, half-rack width) unit, and at a very competitive price point.

The MA60 will find many applications in the Retail, Hospitality, Licensed Premises and other entertainment markets and is the most feature rich of the Utility Mixer/Amps on the market which also offers the best sound quality and the traditional Cloud reliability.

Single Zone, 60w, 4Ω Output as Standard with Optional 50w, 70/100v Internal Transformer (CXL-50T).

• Four-input mixer-amplifier with integral 60w, 4Ω mono power amplifier
• Optional 70/100v Internal Transformer (CXL-50T)
• Gain trims on all inputs
• Electronically-balanced mic input
• 3.5 mm jack input (LINE 2) for MP3 player, laptop, etc.
• Overall HF & LF EQ adjustment
• Short-to-ground access connector or VOX-triggered paging on mic input
• Selectable LINE 4 priority over other music inputs
• Music Mute control input (NO or NC) for interface to emergency system
• Compatible with standard Cloud remotes – RL-1 (music level) and RSL-4 (music level and source selection)
• Electronically-balanced pre-amp output
• Transformer-isolated auxiliary output with independent mic and music level control - for use with telephone MOH systems
• Aux output source selection (internal jumper) – fixed source or follow main output
• Dimensions (mm) - 213.0 wide x 88 high (2U) x 278 deep (+ connectors & knobs)
• Optional Rack Kits (RE-S & RE-L)
