CHIEFMIWRFU
The MIWRF brings in-wall swing arm technology to the next level, creating a flush installation for any flat panel display.
* Get perfect TV centering without cutting studs
* Ultra low-profile mounting solution
Features:
* Provides limitless centering of the flat panel on the wall between 16" center studs without cutting studs - no header/footer necessary
* Low-profile design hides the mount behind the display
* Centris Technology provides smooth, fingertip tilt
* Provides post-installation height adjustment
* ClickConnect Technology provides an audible click to confirm that the flat panel is locked in place
* Screen can be installed in portrait or landscape orientation ( MAC400 accessory can be used to rotate without removing the screen)
* Integrated cable management
* Ships as complete in-wall swing arm - zero assembly required
Specifications:
* Roll: +/- 2°
* Tilt: +2°, -15°
* Swivel: 37° Left/Right
* Extension: 9.9" (251 mm)
* Height Adjustment: 1" (25 mm)
* Dimensions (HxWxD): 17.2" x 20.34" x 5.58" (437 x 517 x 142 mm)
* Color: Black
* Weight Capacity: 125 lbs (56.7 kg)
NOTE: Dimensions do not include interface bracket
