Chief LVS1U - Clearance Product

Clearance Product - Note this product has been box damaged. Please see photos provided. Please contact your Account Manager for further information.

ConnexSys™ Video Wall Landscape Mounting System with Rails

Chief's ConnexSys Video Wall Mounting System solves common video wall challenges of speed, alignment, serviceability and rigidity. The ConnexSys Video Wall Mounting System provides the ability to level each row once by using strut channel to connect multiple mounts together with a simple-to-install system that can handle the largest requirements


The LVS1U ConnexSys Video Wall system landscape mount ships with rails for each mount.

Features
SPEED
Hang units on a single strut channel for quick row leveling
No need for horizontal spacers
Vertical measurement is simply the height of the display to the next rail
Compatible with most 1-5/8" sizes of channel strut
Reduces installation time - especially for XL and recessed configurations
Tool-free ClickConnect™ latching secures displays
PowerZone™ provides 6 points of adjustment in one easy-to-access location at the top of the mount


ALIGNMENT
PowerZone™ Adjustments
Height adjustment ±1" on each interface
Tilt adjustment at single pivot point, protects displays from twisting
Depth can be set between 4" and 7.4" from the wall, providing a range of "home positions" ideal for recessed installations
Both sides adjust independently, compensating for imperfections in the wall
Walls can be out of alignment by up to 2" (horizontally)
3 levels of lateral adjustment
1.Mount left/right along rail
2.Interface left/right along mount
3.Lock in lateral guide for fine-tune adjustment using turn knobs, protecting screens from potential collisions


SERVICEABILITY
RapidDraw™ Display Release
Cord release system gently and remotely pops any screen out for easy access and can be extended 13.4" for service
Protects displays by not requiring an aggressive push to release/pop-out
Releases only on demand, preventing accidental pop-outs
Cord can be set up to pull for release from any 90 degree angle
Kickstand provides 20 degrees of bottom tilt access


RIGIDITY
Rigid frame keeps displays where you set them, even after extending for service
Adjustable home depth position locks screens in place to maintain alignment despite accidental bumps/pushes


MISCELLANEOUS
Security - pad lock ¼" shank diameter
Safety tested
Universal interface
Each mount comes out of the box with adjustments set in the exact same position
