C2G - LegrandAV 89918

Mfr. Part #: 89918 Our Part #: C2G89918
Your Price:  N/A
Qty. Login to see stock. Login to buy

3m Cat6a Booted Shielded (STP) Network Patch Cable, Black

Protect 10 Gigabit data transmissions from 10GBase-T ports and equipment in high noise environments.

Product #: 89918
Connector 1: (1) RJ-45 Male
Connector 2: (1) RJ-45 Male
Colour: Black
Length: 3m

Product Description
This Booted Shielded Cat6a patch cable is ideal for use with 10GBase-T ports and equipment, such as network adapters, hubs, switches, routers, DSL/cable modems and patch panels, and will protect a high speed 10 Gigabit network connection from noise and electromagnetic interference. For voice/data/video distribution, this cable will handle bandwidth-intensive applications and drastically reduces both impedance and structural return loss (SRL). Each patch cable is fully tested to meet ANSI/TIA 568 C.2 Cat6a component requirements.

Each of the individual pairs is bonded together to help maintain the twist-spacing throughout the line right up to the termination point. Constructed from high quality cable and plugs, this design minimises Near-End Crosstalk (NEXT) levels. The moulded, snagless boot prevents unwanted cable snags during installation and provides extra strain relief. Available in a variety of colours to easily color-coded a network installation. Each cable is individually labelled with the length for ease of use.

ISO/IEC 11801: S/FTP (Shielded/ Foiled Twisted Pair); Overall braided Shielding, over four Foil-shielded Twisted Pairs.

Product Specifications
Colour: Black.
Length: 3.00 Meter.
Jacket Rating: Standard Non-Rated.
UPC: 757120899181.
Warranty: Lifetime.
Vendor: C2G.
Weight: 0.131 KG.

Physical Specifications
Cable Type: Stranded SSTP.
Wiring Scheme: 568B.
Temperature Rating: 75°C.
Testing: ANSI/TIA 568 C.2 Cat6a component tested.
ISO/IEC 11801: S/FTP (Shielded/ Foiled Twisted Pair).

Conductor (4 Pair)
Conductor Type: 26AWG (7/0.16) (bare copper).
Insulation: FM-PE.

Overall Cable
Foil Shield: Aluminium foil (100% coverage).
Braided Shield: Copper braid (40% coverage).
Jacket: PVC.

Connector
Connector Type: RJ-45 Male
Shell: Nickel plated for shielding
Housing: Polycarbonate, UL94V-0
Contacts: 50µm gold plated
Hood: Moulded Snagless PVC UL94V-0
Dimension (L x W x H): 38.2 x 11.6 x 15.1

Features
Product TypeCat6 Shielded/Cat6A & Cat7 Patch Cable
ColourBlack
Length3.0m
