7m Cat6a Shielded Booted Network Patch Cable - Grey

7m Cat6a Shielded Booted Network Patch Cable - Grey

Protect 10 Gigabit data transmissions from 10GBase-T ports and equipment in high noise environments.

Product Description

This Booted Shielded Cat6a patch cable is ideal for use with 10GBase-T ports and equipment, such as network adapters, hubs, switches, routers, DSL/cable modems and patch panels, and will protect a high speed 10 Gigabit network connection from noise and electromagnetic interference. For voice/data/video distribution, this cable will handle bandwidth-intensive applications and drastically reduces both impedance and structural return loss (SRL). Each patch cable is fully tested to meet ANSI/TIA 568 C.2 Cat6a component requirements.

Each of the individual pairs is bonded together to help maintain the twist-spacing throughout the line right up to the termination point. Constructed from high quality cable and plugs, this design minimises Near-End Crosstalk (NEXT) levels. The moulded, snagless boot prevents unwanted cable snags during installation and provides extra strain relief. Available in a variety of colours to easily color-coded a network installation. Each cable is individually labelled with the length for ease of use.

ISO/IEC 11801: S/FTP (Shielded/ Foiled Twisted Pair); Overall braided Shielding, over four Foil-shielded Twisted Pairs.

Product Specifications

Colour : Grey
Length : 7.00 Meter
Jacket Rating : Standard Non-Rated
UPC : 757120899068
Warranty : Lifetime
Vendor : C2G
Weight : 0.292 KG

Physical Characteristics

• Cable type: Stranded SSTP
• Wiring scheme: 568B
• Temperature rating: 75°C
• Testing: ANSI/TIA 568 C.2 Cat6a component tested
• ISO/IEC 11801: S/FTP (Shielded/ Foiled Twisted Pair)

Conductor (4 pair)

• Conductor type: 26AWG (7/0.16) (bare copper)
• Insulation: FM-PE

Overall cable

• Foil shield: Aluminium foil (100% coverage)
• Braided shield: Copper braid (40% coverage)
• Jacket: PVC

Connector

• Connector Type: RJ-45 Male
• Shell: Nickel plated for shielding
• Housing: Polycarbonate, UL94V-0
• Contacts: 50µm gold plated
• Hood: Moulded Snagless PVC UL94V-0
• Dimension (L x W x H): 38.2 x 11.6 x 15.1

Product Features

• Snagless booted design protects clips when plugging and unplugging
• Standard shielded RJ45 connectors and shielded twisted pair wires
• Available in 4 colours to colour-code a network
• Available in lengths up to 30m

Features
Product TypeCat6 Shielded/Cat6A & Cat7 Patch Cable
