C2G - LegrandAV 85609

Mfr. Part #: 85609 Our Part #: C2G85609
Your Price:  N/A
Qty. Login to see stock. Login to buy

10m Yellow LC-LC 9/125 OS2 Duplex Singlemode PVC Fibre Optic Cable (LSZH)

9/125 micron cable for Gigabit Ethernet applications where protection from toxic and corrosive gases is critical

Connector 1 : (1) LC Male
Connector 2 : (1) LC Male

Product Description

Cost-effective solution that provides high bandwidth and transmission rates over longer distances. With LC to LC termination, this high quality fibre optic patch cable is specifically designed for Gigabit Ethernet applications.

The Low Smoke Zero Halogen (LSZH / LS0H) jacket is composed from materials that lessen the smoke and halogen emissions when the cable is exposed to extreme temperatures.

This reduces the amount of harmful toxic and corrosive gases that cabling made with plastic materials would otherwise emit into the air during combustion. This construction makes LSZH cables ideal for use where the protection of people and equipment from harmful corrosive gases is absolutely critical.

The patented injection moulding process provides each connection greater durability in resisting pulls, strains and impacts from cabling installs.

Each cable is 100% optically inspected and tested for insertion loss before you receive it. A pull-proof jacket design surrounds the popular 9/125 Single-mode fibre, immune to electrical interference.

Product Specifications

Colour : Yellow
Length : 10.00 Meter
Jacket Rating : Standard Non-Rated
UPC : 757120856092
Warranty : Lifetime
Vendor : C2G
Weight : 0.084 KG

• Download the technical specifications on this product from the Support tab

Connectors:

• LC Connector Dimensions: 10.75mm Height x 12.5mm Width x 50mm Depth (with installed duplex clip)

Cables:

• Maximum Connector Loss: 0.50 dB
• Typical Connector Loss: 0.30 dB
• Typical Return Loss: -55 dB
• Buffer Material: PVC
• Buffer OD: 900 µm
• Jacket Material: LSZH PVC (OFNR riser-rated)
• Jacket OD: 1.8 mm
• Installation Tensile Load: 100 N (445 lbs)
• Long-Term Tensile Load: 50 N (222 lbs)
• Maximum Tensile Load: 100 N/cm
• Installation (Loaded) Minimum Bend Radius: 5.0cm (1.97in)
• Long-Term (Unloaded) Minimum Bend Radius: 3.0cm (1.2in)
• Crush Resistance: 750 N/cm
• Impact Resistance: 1,000 cycles
• Flex Resistance: 5,000 cycles
• Attenuation at 1550 nm: 0.25 dB/km
• Attenuation at 1310 nm: 0.35 dB/km
• Operating Temperature: -20°C to +70°C

Please Note: Attenuation testing performed in accordance with EIA/TIA-455-171A.

Features
Product Type9/125 Single Mode Fibre Patch Cables
ColourYellow
Length10m
