2m Mini DisplayPort Male to DisplayPort Male Adapter Cable 4K 30Hz, Black
Connect the Mini DisplayPort or Thunderbolt™ output of a computer to the DisplayPort input of a computer monitor and support a digital audio/video connection up to a 4K resolution
• Product #: 84301
• Connector 1: (1) Mini DisplayPort Male
• Connector 2: (1) DisplayPort Male
Product Description
This Mini DisplayPort to DisplayPort Adapter Cable allows you to connect the Mini DisplayPort output of a video source to a display which accepts a DisplayPort input ― making it an ideal solution for the office or work space applications. This adapter cable is a perfect accessory for Microsoft® Surface® products and other leading laptops.
The cable form factor of this adapter provides a simple and convenient solution that eliminates the need for a separate adapter and cable, reducing possible failure points.
This cable is a simple plug and play solution, supporting high-definition resolutions up to 4K (4096 x 2160 at 30hz), allowing it to deliver a high quality video image to the connected display.
Product Features
• Directly connect a Mini DisplayPort output to a DisplayPort input
• Carries a digital audio/video signal
• Supports resolutions up to 4K (4096 x 2160 at 30Hz)
• Built to DisplayPort 1.2 standards
• Compatible with the Microsoft® Surface® Pro 6, Surface Laptop 2, and other leading laptops
Product Specifications
• Colour: Black
• Length: 2.00 Meter
• Jacket Rating: Standard Non-Rated
• UPC: 757120843016
• Warranty: Lifetime
• Vendor: C2G
• Weight: 0.087 KG
Electrical Specifications
• Voltage Rating: 30v
• Conductor Resistance: @ 20°C max
• Insulation Resistance: 10MΩ/km
• Time Delay: 5.2ns/m (max)
• Attenuation: 5.02dB@100-450MHz, 7.69dB@1GHz, 12.595dB@2GHz, 17.495dB@3GHz, 22.395dB@4GHz, 27.295dB@5GHz, 32.195dB@6GHz 37.095dB@7GHz
Physical Specifications
• Minimum Bend Radius: 52mm
• Approvals: CE
• Warranty: Lifetime
Conductor (5 pair)
• Conductor:,/strong> 32AWG (7/0.08TC)
• Insulation: FM-PE, ID:0.62±0.05mm
• Color: White/Black, White/Brown, White/Red, White/Green, White/Blue
• Drain: 1:32AWG (7/0.08TC)
• Shield:,/strong> AL-Foil Wrap, Transparent Wrap
Conductor (5 Conductors)
• Conductor: 32AWG (7/0.08TC)
• Insulation: PP, ID:ø0.5±0.05mm
• Color: Red, Blue, Purple, White, Gray
Overall Cable
• Jacket: PVC
• Shield: AL-Foil Wrap, Braid, 85% Min Coverage
• Drain:• 2:30AWG (7/0.10 BC)
• OD:• 5.2±0.15
