C2G - LegrandAV 80694

The DisplayPort Male to HDMI Male Active Adapter Cable allows you to connect the DisplayPort output of a video source to a display which accepts an HDMI input # making it an ideal solution for the office or work space applications.

Convenience
The cable form factor of this adapter provides a simple and convenient solution that eliminates the need for a separate adapter and cable, reducing possible failure points.

Performance
This cable is a simple plug and play solution and carries an active video signal, supporting high-definition resolutions up to 4K (4096 x 2160 at 60hz), allowing it to deliver a high quality video image to the connected display.

Features and Benefits

• Support for resolutions up to 4K (4096 x 2160 at 60hz)
• Adapter in cable form factor
• Active DisplayPort 1.2 to HDMI 2.0 conversion
• Support for 3D video and HDCP 2.2
• Plug and Play — no driver required

Electrical Specifications

• Voltage Rating: 30V
• Conductor Resistance: 30AWG-381 /km Max. at 20°C
• Insulation Resistance: FOAM-PE/PE DC-500V 100M . km Min. at 20°C
• Dielectric Strength: AC 500V/1 Sec. Min.
• Impedance: 100±5


Physical Specifications

• Operating Temperature: 0°C to 50°C
• Storage Temperature: -25°C to 70°C
• Connector 1: DP Male: Nickel Plated Shell: SPCC; Gold Plated Terminal: C5191; Black Core: LCP
• Connector 2: PCBA/Mini DP to HDMI A/M Plywood, Black Rubber Core (IC: PS176) PCB 'A, Nickel Plated Connector (Fog Surface) HDMI M Connector, Nickel Plated Shell: C2680; Gold Plated • Terminal: C5191; Black Core: LCP
• Shell: Connector 1, Connector 2: Black ABS Finish Shell, SR Molding Black PVC
• Cable OD: 6.0, (7/0.10Tx1P+D+AL+Mylar)x5P+7/0.10Tx5C+F+ADB16/5/0.12, Jacket PVC Black
• Cable Marking: DisplayPort Cable E301195 UL AWM Style 20276 80°C 30V VW-1
• QC Inspection
• 100% Test for Open/Short
• Mechanical Test for Connectors
• Mean Time Between Failure is 400,000 Hours
• Approvals: CE marked and conforms to 2011/65/EU ROHS 2
