Bosch LBC1420/20

Mfr. Part #: F.01U.026.720 Our Part #: BOSCHLBC142020
Your Price:  N/A
Qty. Login to see stock. Login to buy

• 12 W, 36 W and 100 W versions
• Available in power-save or failsafe versions
• Built-in 24 VDC override relay
• Continuous rotating system
• Suitable for 3-wire and 4-wire systems
• Program selector with up to five channels
• Optional surface mounting box
• Complies with international installation and safety regulations


Public address systems are often used for both announcements and background music distribution. Volume controls can be used to adjust the level locally. In addition to volume control, program selectors can also be installed to select five different programs locally. In the event of an (emergency) announcement,
the built-in relay ensures that the message is broadcast at a preset level, independent of the local volume setting. The volume controls come in three versions according to power rating: 12 W, 36 W, and 100 W. The total load of the loudspeakers connected to a volume control may not exceed the rated power. Each of the three versions is also available in two versions. One is a power-saving, 4-wire volume override (/10 models), where the override relay is activated during an emergency call. The other is a failsafe, 4-wire volume override (/20 models), where the override relay is deactivated during an emergency call.

EAN # : 8717332254347.
