Biamp Community V2-212SB
5 Years Warranty
Product Highlights
• Powerful LF output.
• Cool-Coil technology and DYNA-TECH™ protection circuitry.
• Low profile design.
Product Overview
The V2-212S is a low-profile, dual-driver subwoofer system designed to augment and extend the low frequency output of any E or V SERIES full-range loudspeaker system. Powerful and low in distortion, the V2-212S produces authoritative low frequency output. The result is a deep, but punchy sonic signature that can handle most any musical style with ease. Solidly constructed of cross-laminated birch plywood, this subwoofer provides an accurate acoustic response uncolored by enclosure resonance. Its small size makes it a perfect fit for jazz clubs, bars, restaurants, worship centers, AV presentations, and other applications that require extended bass, but do not have the space available to install larger, bulkier systems.
The enclosure may be suspended from its M10 threaded rigging points, or simply located on the floor. As with all subwoofers, a corner placement is recommended when possible, in order to take advantage of the acoustical boundary effect for the highest possible efficiency. The V2-212S includes Community’s exclusive DYNA-TECH™ driver protection circuitry to protect against abusive operating conditions, and also features Community’s patented Cool-Coil™ heat evacuation technology to minimize cone driver power compression and ensure long term reliability.
The V2-212S is a versatile performer for applications requiring high quality, high power, and extended low frequency response at a reasonable cost.
Product Specifications
• Finish: Black painted 11-ply cross-laminated birch with dual-layer powder-coated steel grille.
• Dimensions (H x W x D): 13.92" x 35.91" x 17.92" (354 x 912 x 455 mm).
• Nominal Beamwidth (H x V): 360° x 180°.
• Power Handling: 300W continuous @ 4 ohms.
• Continuous Max Output: 123 dB (129 dB Peak).
• Sensitivity (1W/1m): 98 dB.
• Transducers: LF - 2 x 12”.
• Operating Range: 37 Hz – 500 Hz.
