Tesira EXIN
5 Years Warranty
Product Overview
The Tesira EX-IN is a half-rack expander box for use with AVB-enabled Tesira server-class devices. The EX-IN is a 4-channel mic or line level audio input expander. The expander communicates with the Tesira AVB network for audio networking, configuration, and control, and is powered by PoE+.
Key Features
• Four channels of balanced mic or line level input.
• 0 – 66dB gain, adjustable in 6dB increments.
• +48V Phantom Power.
• -100 to +12dB fader range for level.
• Audio and control networking over AVB/TSN.
• Powered by PoE+.
• Plug-in barrier strip connectors.
• Front panel LEDs for device status indications.
• Half-rack chassis.
• RoHS compliant and AES grounded.
• Covered by Biamp Systems’ five-year warranty.
