Biamp Community DP8-B
Product Highlights
• High intelligibility with wide dispersion, uniform voicing.
• Stylish contemporary design.
product Overview
The DP8 is a high performance 8-inch pendant loudspeakers designed for open architecture spaces or any location where a stylish pendant form factor is desired. Featuring high power handling, higher sensitivity and realistic sound reproduction, the DP8 is the more focused big brother to the DP6. D SERIES pendant loudspeakers can be used in a wide variety of speech and music applications. They are equipped with a built-in autoformer, supporting low impedance or 70V/100V operation. Uniform voicing means that the DP8 can be combined with other ceiling and surface mount models in the C or D SERIES family without compromising consistency from zone to zone. The genuine coaxial design uses separate magnets for the LF and HF drivers for reduced distortion and industry-leading sensitivity, thereby permitting 3 dB to 6 dB greater output level while requiring half the amplification power of competing products. An easy-access selector switch is conveniently located on the face of the loudspeaker for selectable 8 ohm or 70V/100V operation, while an integrated rear cover hides all wiring and hanging hardware for an aesthetically pleasing installation.
Product Specifications
• Finish: Black or white paintable ABS matte plastic, dual-layer powder-coated steel grille.
• Nominal Beamwidth (H x V): 115° Conical.
• 70V/100V Autoformer: 120W, 60W, 30W, 15W (@70V only).
• Continuous Max Output: 117 dB (123 dB Peak).
• Power Handling: 150W continuous @ 8 ohms.
• Operating Range: 60Hz – 22 kHz.
• Sensitivity (1W/1m): 95 dB.
• Dimensions (H x Dia): 17.7" x 13.4" (450 x 341 mm).
• Transducers: LF -1 x 8”, HF - 1 x 1.25” exit compression driver.
5 Years Warranty
