DEVIOSCR20C WHITE
The Devio SCR-20 is a conferencing hub that provides users with exceptional AV experiences when using web-based conferencing systems. Intended for huddle rooms or small conference rooms, the SCR-20 uses Beamtracking™ microphones and professional grade DSP to optimize the audio quality, allowing far-end conference participants to experience the conversation naturally. The Devio SCR-20 supports a variety of room designs for computer-based conferencing including a BYOD approach or connection via a dedicated in-room PC. Devio works in concert with PCs running a variety of web-based conferencing solutions including Microsoft Skype for Business/Microsoft Teams, Zoom, BlueJeans, Google Hangouts™/Google Meet, and many more. For ease of network and device management, Devio can be monitored and managed remotely via SNMP or with the Devio System Administration Utility (SAU) software, and firmware updates can be scheduled and deployed to multiple Devio units as needed.
• Works in concert with PCs running web-based conferencing solutions, including Microsoft Skype for Business/Microsoft Teams, Zoom, BlueJeans, Google Hangouts™/Google Meet, and many more
• Supports both Windows and Mac PCs, and uses standard audio drivers
• Supports driverless, pass-through HDMI connectivity to a single in-room display, or to two monitors with USB video using DisplayLink USB graphics technology (requires installation of DisplayLink driver on laptop; supports Windows 7, 8, 8.1, and 10)
• Auto Setup validates device connections, adjusts room levels, and sets speaker EQ to optimize audio quality
• Can be monitored and managed remotely via SNMP or with the Devio System Administration Utility (SAU)
• Firmware updates can be scheduled and deployed to multiple Devio units via the SAU
• Speaker connectivity options include HDMI audio, a built-in 20W amplifier, or RCA line out
• Includes a mounting bracket for under–the–table installation
• Ships with one tabletop or ceiling Beamtracking microphone with 360-degree coverage
• Covered by Biamp Systems’ five-year warranty
DCM-1
The DCM-1 ceiling microphone includes Beamtracking™ technology with three 120-degree zones, providing full 360-degree coverage of the meeting space. The DCM-1 microphone actively tracks and intelligently mixes conversations from around the table, allowing far-end conference participants to experience the conversation naturally. The Devio DCM-1 has four software-selectable elevation angle modes for optimal sound pickup, and a second DCM-1 microphone can be added to the meeting room if needed.
• Beamtracking technology actively tracks and intelligently mixes conversations around the table
• Three 120-degree zones for 360 degrees of coverage
• Three LED mute status indicators
• Four selectable elevation angle modes
• User-adjustable mic height
• Pendant microphone available in either white or black
• Optional tile bridge mounting accessory available
• Easy single-cable installation process
• Evaluated to the requirements of UL 2043 and is suitable for use in air handling spaces
• Additional RJ-45 for daisy-chain connection to another DCM-1 microphone (maximum of two mics per daisy chain)
• Covered by Biamp Systems' two-year warranty
