Atlona Technologies AT-HDR-CAT-4ED

Mfr. Part #: AT-HDR-CAT-4ED Our Part #: ATLHDRCAT4ED
Your Price:  N/A
Qty. Login to see stock. Login to buy

Four-Output Extended Distance 4K HDR HDMI to HDBaseT Distribution Amplifier

Long Distance HDMI to HDBaseT Distribution

Send a single 4K HDR source to four displays at distances up to 330′ (100 m) for video distribution applications including hospitality and retail, commercial reception areas or warehouses, and educational AV systems that require multiple screens.

4K HDR Support

Provides 4K/UHD capability @ 60 Hz with 4:4:4 chroma sampling as well as HDR10, HLG, and Dolby® Vision™ HDR formats for very high, pristine image quality.

Sophisticated Integration Capabilities

Features and capabilities designed to ease integration in commercial AV distribution applications include HDMI pass-through, audio de-embedding, EDID management, CEC display control, RS-232 and IR control extension, remote power for receivers, and HDBaseT link testing.

Unique Features

The Atlona AT-HDR-CAT-4ED is a high dynamic range (HDR) distribution amplifier with one HDMI® input and four extended distance HDBaseT™ outputs. Each output transmits 4K/UHD video @ 60 Hz with 4:4:4 chroma sampling plus support for HDR formats up to 330 ft. (100 m). Also includes integration capabilities designed for commercial AV distribution applications.

4K HDR Support

4K/UHD capability @ 60 Hz with 4:4:4 chroma sampling as well as HDR10, HLG, and Dolby® Vision™ HDR formats.

Long Distance Extension

HDBaseT outputs extend 4K/60 HDR up to 330 feet (100 meters).

Display Control

CEC display control sends display power on/off commands over HDBaseT using the power button, IP, or RS-232.

Audio De-embedding

De-embed HDMI audio to a balanced analog output with volume control for integration with a separate audio system

Features
Dimensions (W x H x D)219.5 x 44 x 254 mm
Weight1.7 Kg
