Atlona Technologies AT-UHD-SW-5000ED

The Atlona AT-UHD-SW-5000ED is a 5 x 1 switcher with two HDBaseT inputs, three HDMI inputs, mirrored HDMI and HDBaseT outputs, balanced audio outputs, automatic input selection, and automatic display control capability. The HDBaseT inputs match perfectly with the HDVS-200-TX modules to enable VGA and HDMI sources to be easily integrated into a system. The switcher supports 4K/UHD @ 60 Hz, 4:2:0; (10.2 Gbps). It transmits AV signals along with Ethernet, power, and control over a single cable to displays up to 328 feet (100 meters) from the switcher. Control options include automatic input selection, front-panel buttons, and compatibility with IR, RS-232, or TCP/IP-based control systems. Displays are automatically turned on and off using CEC, IP, or RS-232.

The AT-UHD-SW-5000ED enables two HDVS transmitters to be used in a single system. With Ethernet enabled HDBaseT transmission to the HDVS transmitters and the receiver control, setup and maintenance is simplified. Automatic input selection and display control simplify the system, reducing cost, reducing setup time and resulting in a better end user experience.

Two, Ethernet-enabled HDBaseT Inputs
• Supports two HDVS-150 or HDVS-200 Series transmitters for placement at remote sources near lecterns, conference tables, and instructor’s desks
• Simplifies integration of remote sources by eliminating power supplies when used with PoE-powered transmitters; single category cable carries AV signals, control and power

Mirrored, dual outputs on HDMI and HDBaseT
• Supports dual display environments with local and extended distance 328 foot (100 meter) displays
• Eliminates cost associated with extra extension components; simplifies installation. HDMI output can be used with additional HDBaseT transmitter

Automatic display control
• Automatically changes projector power state based on active or standby mode of switcher. Control signals transmitted via CEC, IP, or RS-232
• Eliminates need for complex control system in AV systems. Enables display and volume control directly. CEC enables control of low-cost consumer displays
• Any product that has mirrored output with HDMI and HDBaseT will have CEC functionality through the HDBaseT output

Automatic input selection using hot plug detect and video detection technology
• Selects active input when sources are connected or if there is a change in source power status
• Eliminates need for complex control system in AV systems

Ethernet-enabled HDBaseT
• Simplifies installation, maintenance with IP controlled switcher, transmitters and receivers using Atlona AMS
• Configure, backup, update, maintain and monitor from a simple PC interface

IR, RS-232 and Ethernet HDBaseT insertion
• Adds internally-generated or externally-generated display control signals to the HDBaseT transmission
• Simplifies display control from third-party control systems

EDID management and HDCP management
• Manages EDID communications between source and display; allows integrators to force sources to preferred resolution
• Ensures desired audio formats and video resolutions are provided to the AV system; enables PC output to non-compliant codecs

4K/UHD capability
• Compatible with Ultra High Definition sources and displays
• Supports high-resolution applications such as CAD, desktop publishing, and detailed financial reporting
• Supports up to HDCP 1.4 (Does not support HDCP 2.2 devices)

AV, Ethernet, power and control over HDBaseT
• Delivers 4K/UHD video, audio, 100Base-T Ethernet, power and control through a single cable
• Eliminates multiple cable runs between source, control system router and display

Power over Ethernet for remote-powered HDBaseT receivers
• Industry standard IEEE 802.3af PoE supplied by the switcher over HDBaseT
• No local AC outlet required; saves time and integration costs

TCP/IP, RS-232, and IR control
• Flexible control options compatible with 3rd-party control systems
• Reduces integration time and costs

Easy, GUI-based configuration using integrated web server
• Offers menu-based configuration of network settings, RS-232 settings, input switching, EDID, and HDCP management and audio
• Allows fast configuration of internal product settings and troubleshooting from a tablet, smart phone, or PC in the field

Volume controls
• Volume up and volume down button adjust output level to sound system
• Alternatively send RS-232 or TCP/IP commands to external control device

Volume setting indicator
• Displays volume level of the switcher
• Provides quick indication of level during setup

Balanced, line level output
• Reduces noise and requirement for external components
• Matches requirements of commercial sound systems

Multi-channel audio compliant
• Supports PCM, Dolby® Digital, Dolby Digital Plus™, Dolby TrueHD, Dolby Atmos®, DTS Digital Surround™, and DTS-HD Master Audio™
• Allows any multi-channel audio stream to be used within a professional audio system
• Note: Only PCM sources are de-embedded and routed by the AT-UHD-SW-5000ED

Rack-mountable, 1U, half rack width enclosure
• Installs easily in rack-mounted systems with included 19” rack-mount brackets
• Simplifies installations; allows two units to be mounted together

Works with AMS
• This IP-controllable product can be remotely managed by the Atlona Management System software
• Integrates product configuration, management, and updates to reduce installation time and enable remote support

Included accessories
• User guide, desktop power supply, detachable power cable, IR hand held remote control, rack mount bracket kit

Award-winning 10 year limited product warranty
• Ensures long-term product reliability and performance in residential and commercial systems
• Specify, purchase, and install with confidence
