ATEN VM8814-AT

Aten VM8814-AT

Product Key Features
• Compatible with the VM1600 / VM3200; mix and match with modular I/O boards of any type for optimum flexibility
• 4K Scaler: Features a video scaling function to convert input resolutions to the optimum display resolutions.
• Seamless Switch™: Features close-to-zero second switching that provides continuous video streams, real-time switching, and stable signal transmissions*.
• FrameSync: Prevents image tearing by synchronizing the scaler output frame rate to the input signal frame rate.

Product Overview
The VM8814 is a 4K HDMI output board that works with an ATEN Modular Matrix Switch to offer an easy way to route 4 HDMI sources to 4 displays. In addition to the HDMI interface that carries digital A/V signals, the VM8814 is equipped with 4 stereo audio output ports that allow HDMI audio extraction.

Considering the need for fast video switching and resolution adaptation in video wall applications, the VM8814 supports Seamless Switch™ and EDID Expert™ that make real-time video switching possible, and contains a built-in 4K scaler that handles different video resolutions. The ATEN VM input/output boards support hot-swappable installation that gives system integrators great flexibility and efficiency for maintenance. The ATEN VM input/output boards along with ATEN Modular Matrix Switches offer ideal solutions that perfectly meet your demands for video-critical applications.

Product Package Contents
• 1x VM8814 4K HDMI Output Board.
• 4x Terminal Blocks.
• 1x User Instructions.

More Product Key Features
• 4-port HDMI Output Board that is compatible with the VM1600/VM3200 and can be mixed with modular I/O boards of any type for optimum flexibility.
• Superior Video Quality: HDTV resolutions of 480p, 720p, 1080i and 1080p (1920 x 1080); 4K2K@60 (4:2:0).
• Audio-enabled, HDMI audio can be extracted.
• 4K Scaler: Features a video scaling function to convert input resolutions to the optimum display resolutions.
• Seamless Switch™: Features close-to-zero second switching that provides continuous video streams, real-time switching, and stable signal transmissions*.
• Video Wall: allows you to create custom video wall layouts via an intuitive web GUI*.
• EDID Expert: Selects optimum EDID settings for smooth power-up and the highest quality display
• HDMI (3D, Deep Color); HDCP 2.2 Compatible.
• Cable Quality Tester: Examines the HDMI cable quality.
• FrameSync: Prevents image tearing by synchronizing the scaler output frame rate to the input signal frame rate.
• Consumer Electronics Control (CEC) support.

*Note:
1. When Seamless Switch™ is enabled, 3D, Deep Color, or interlace (i.e., 1080i) formats will not be supported. To use these formats, make sure to disable Seamless Switch™.
2. Videos may not display within range when Seamless Switch™ or Video Wall is enabled, in which case please adjust the display settings on your device.

Product Specifications
Video Output
• Interfaces: 4 x HDMI Type A Female (Black)
• Impedance: 100 Ώ
• Max. Distance: Up to 15m.

Video
• Max. Data Rate: 10.2 Gbps (3.4 Gbps Per Lane).
• Max. Pixel Clock: 340 MHz.
• Compliance: HDMI (3D, Deep Color, 4K), HDCP 2.2 Compatible, Consumer Electronics Control (CEC).
• Max. Resolution: 4096x2160/3840x2160@60Hz (4:2:0);, 4096x2160/3840x2160@30Hz (4:4:4).

Audio
• Output: 4 x Captive Screw Connector, 5 pole.
* Audio signal type: stereo, balanced/unbalanced.

Power Consumption
• 20W:94BTU.

Environmental
• Operating Temperature: 0 - 40°C.
• Storage Temperature: -20 - 60°C.
• Humidity: 0 - 80% RH, Non-Condensing.

Physical Properties
• Housing: Metal.
• Weight: 0.65 kg ( 1.43 lb ).
• Dimensions (L x W x H): 35.20 x 23.80 x 2.33 cm (13.86 x 9.37 x 0.92 in.).

Carton Lot
• 2 pcs

Note
• For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.

EAN # : 4719264646218
