Ampetronic W5-2
|
Qty. | Login to see stock. | Login to buy |
The W5-2 is designed particularly for small rooms where there is no AV rack and no network monitoring requirements, but can still make use of Ampetronic’s industry leading spill control design.
• Input 1 & 2 – 3 way 3.5mm euroblock screw terminal input
• Balanced mic/line selectable
• 100V line input – 2 way 5mm euroblock screw terminal
• Phantom Power – 24V (switchable on both channels)
• Loop Output Drive Current – W5-2 – 5A RMS per channel
• Loop Output Connectors – 2 way 5mm euroblock screw terminal per channel
• Built-in Test Tones (1KHz sine, Pink noise)
• Phase shift – 90° (always on)
• Metal Loss Correction – 0 to 3dB per octave frequency correction (1KHz remains constant)
• Three stage inductance compensation – to correct frequency response with different loop lengths
• DC Out – 24V DC
