Product Overview
The CLD1 Compact Loop Driver is designed for counter systems and small area perimeter loop systems. Measuring only 128 x 74 x 35mm and with an output current of 2.4A RMS, the CLD1 is the smallest and highest performance amplifier in its class. Designed and built to Ampetronic’s high standards of reliability, backed with a 5 year warranty and Ampetronic support, the CLD1 offers certainty of performance and the lowest lifetime cost available.

Audio quality is ensured with metal loss correction (MLC) combined with Ampetronic’s usual high standards of design. The CLD1 is designed for flexibility and convenience, featuring 2 separate microphone inputs with independent level controls, one of which can be configured as a line input.

All cable connections are made on a single face of the unit, adding flexibility and further simplifying installation.

Applications Include
• Ticket and service counters.
• Retail counters.
• Information kiosks.
• Reception desks.
• Interview rooms.
• Small meeting rooms.
• Taxis and private cars.

Product Information
Counter Loops
When supplied as a counter loop kit, the CLD1 comes with choice of microphone, a multi-turn preformed loop, power supply and simple installation instructions. The loop should be mounted vertically in accordance with the installation instructions. Other installation methods are also available.

The CLD1 in this application will project a field to the requirements of IEC60118-4 approximately 1m from the preformed loop.

Perimeter Loops – Area Coverage (Maximum)
The CLD1 is designed for small perimeter loop applications in rooms or in vehicles.

The CLD1 is DC powered making it ideal for use in small vehicles such as taxis, private cars and small boats. We recommend a multi-turn loop in the headlining of the vehicle cabin – contact Ampetronic for an application guide.

Maximum Cable Length
With maximum current output the CLD1 can drive:

• Loops with DC resistance from 0.3 to 1.0Ω.
• Impedance up to a maximum of 1.3Ω.

When operating below maximum output, the CLD1 can drive longer cable lengths – contact Ampetronic for more details.

Maximum cable length is dependent on cable type and on the application.

CLD001CD
This kit includes the Compact Loop Driver, Desktop Mic, Pre-formed Loop, A6 Loop Present Sign, Installation Guide, Region Specific Power Supply.
