Ampetronic C5-2

Ampetronic C5-2

Product Description

The C Series hearing loop drivers from Ampetronic mark a substantial development in assistive listening technology. C Series units feature digital signal processing and networking functionality, and enable fast, accurate setup and adjustment via a very simple and easy to use user interface.

Ampetronic has engineered the C Series to offer the high end performance, consistency and certainty of results usually associated with top of the range hearing loop drivers, all for the price of a mid-range amplifier. Class ‘D’ drivers built into the C Series ensures low running and maintenance costs.

Network versions enable installers, technicians and facilities managers to remotely control the driver and monitor its condition status along with resistance and induction measurements. Fault condition alerts via email or Telnet provide reassurance that an operator will be informed of any issues with performance delivery.

The C5-2 features 5 Amps RMS current loop output, plus ample voltage headroom, making it suitable for a wide range of applications. Installation can be performed with total confidence; unique, multi-stage filtering ensures compatibility with other systems and global EMC regulations.

Applications Include
• Lecture Theatres & Conference facilities.
• Stadia, Sports Halls, Cinemas & Theatres.
• Courts Rooms, Airports & Railway Stations.

Product Code: C5-2

Product Features
• Simple digital interface enabling accurate adjustment.
• Single or dual output options. Dual outputs featuring accurate and stable 90° phase shiftHighly energy efficient Class-D amplifiers with low heat dissipation providing low running and maintenance costs.
• Networking with browser interface for remote reporting, adjustment, active status monitoring and remote fault reporting via email or Telnet.
• Built-in test tones – controllable with LoopLink.
• AGC and dual slope configurable MLC.
• Compact 1U rack mount unit with internal transformer for simple rack installation.
• Optimised for speech frequencies with unmatched intelligibility and capable of high quality musical reproduction.
• Industry standard Phoenix connectors.
• Data compliant with IEC 62489-1 Standard.
• 100V line input.

Product Standards
These products are designed to form part of a system that can meet all of the requirements of the international loop performance standard IEC60118-4, and the relevant parts of IEC TR 63079. To fully meet requirements of these standards, correct design, installation, commissioning and maintenance are required.

All specification data has been compiled in accordance with IEC62489-1, the international performance reporting standard for audio frequency induction loop equipment. Specification data should only be compared with data compliant to this standard.

This product is CE and RCM marked to all relevant safety and EMC standards, and is MET Labs approved for sale in North America.
