Icron Ranger 2304GE-LAN 4 Port USB2 With UK Power Supply up to 100m Cat5 Extender

The USB 2.0 Ranger 2304GE-LAN provides the ability to connect all USB 2.0 device types to hosts across a Gigabit Ethernet Local Area Network using existing cabling.

Product Key Features

The RG2304GE-LAN extends USB 2.0 peripherals such as flash drives, keyboards, mice, webcams
and interactive whiteboards across a Local Area Network (LAN) and supports isochronous devices
such as webcams.
• Extends USB through 1000Mbps LANs.
• USB 2.0 throughput up to 480Mbps*.
• Pre-paired networked configuration** for simple installation.
• Supplies up to 600mA at each USB port concurrently; 1A per port when two or less
are used.

Includes the ExtremeUSB® suite of features:
• Transparent USB extension.
• True plug and play; no software drivers required.
• Works with all major operating systems: Windows®, macOS™, Linux® and Chrome OS™.

Product Applications
• Remote storage.
• Security and monitoring.
• Industrial Control.
• Keyboard and mouse.

Product Specifications

Range
• Direct Connect: Up to 100m (330 ft) over solid core CAT 5e/6/7.
• Network Connect: Up to 100m (330 ft) between switches over solid core CAT 5e/6/7.

USB Device Support
• Network and Direct Connect: Up to 480Mbps*.
• Traffic Types: All USB 2.0 Traffic Types.
• Device Types: All USB 2.0 Device Types.
• Maximum Number: Up to 30 devices.

Networking
• Standards: 1000BASE-T*.
• Data Traffic: Layer 2.

Local Extender
• USB Connector: 1 x USB Type B Receptacle.
• Link Connector: 1 x RJ45.
• Dimensions: 100mm x 76mm x 26mm (3.9" x 3.0" x 1.0").
• Enclosure Material: Silver Anodized Aluminum.

Remote Extender
• USB Connectors: 4 x USB Type A Receptacles.
• Link Connector: 1 x RJ45.
• Dimensions: 100mm x 76mm x 26mm (3.9" x 3.0" x 1.0").
• Enclosure Material: Silver Anodized Aluminum.
• Available Current: Up to 600mA to each USB port concurrently.
• Power Supply: 100-240V AC Input, 24V 1A DC Output.

Environmental
• Operating Temperature: 0°C to 50°C (32°F to 122°F).
• Storage Temperature: -20°C to 70°C (-4°F to 158°F).
• Operating Humidity: 20% to 80% relative humidity, non-condensing.
• Storage Humidity: 10% to 90% relative humidity, non-condensing.

Compliance
• EMC: FCC (Class B), CE (Class B).
• Environmental: RoHS2/3 (CE).

Support
• Warranty: 2-year.
