Lindy 32369

The SC5-IP KVM Switch is a 16 port KVM switch which allows users to access and control up to 16 different computers from a local or remote location. Its advanced design makes use of CAT5/5e structured cabling to provide high quality linking for both computers and KVM consoles. This allows greater connection distances than when using standard KVM cables. The SC5-IP allows access to the switch via an IP network or internet connection using a Real VNC client application.

Unique CAM (Computer Access Module) technology is used to make the connections to the computers at up to 10m, whilst remote 'User Stations' are used to connect to the operators at up to 300m. CAM modules are available to support a variety of platforms including PCs, Macs and SUN systems.

• 19" rackmount KVM switch which supports up to 16 PC, SUN (USB & 8-pin style), Mac (USB), RS/6000, • Alpha and SGI computers at distances of up to 10m using PS/2, USB or SUN Computer Access Modules
• Supports four simultaneous users
• Up to four users can be linked via optional CAT5 extenders at up to 300m
• Local user(s) can be connected via PS/2, or USB, and VGA
• On-Screen Display for easy control and configuration
• Enterprise grade security features using AES 128 bit encryption and RSA 2048 bit public key authentication
• High resolution support for both local and remote users: up to 1900 x 1440
• IP V.6 protocol supported

A complete range of CAM modules and User Stations is available for use with the KVM Switch SC5.

Technical Information

• Provides 4 concurrent local, remote or global users with BIOS level access to up to 24 multi platform computers
• Audio support when using the appropriate Computer Access Module
• Power control functions are supported via a dedicated serial port
• Dual power inputs for maximum redundancy
• 19" 1U rackmountable (brackets included)
• Compatible with all common operating systems: DOS, Windows 98SE/ME/2000/XP/2003 Server/Vista, • Linux, UNIX, SUN, all Mac OS and Netware

EAN # : 4002888323697
