Icron 00-00329

Icron 00-00329

Product Key Features

Take advantage of USB 3.0's blazing 5Gbps speeds up to 100m of distance over multimode
fiber. Machine Vision cameras, security cameras, conferencing cameras and storage drives can
be extended while providing isolation and security. Key features include:
• USB 3.0 extension up to 100m
• Delivers speed, isolation and security over multimode fiber
• Supports USB 3.0 throughputs of up to 5Gbps
• Integrated 2-port hub suitable for industrial environments
• Rugged locking USB and power connectors
• Enclosures with convenient pre-drilled holes for optional bracket mounting
• Works with AIA USB3 Vision™ compliant devices

Includes the ExtremeUSB® Suite of Features:
• Transparent USB extension.
• True plug and play; no software drivers required.
• Works with all major operating systems: Windows®, macOS™, Linux® and Chrome OS™.

Product Applications

• Machine Vision camera extension.
• Security camera extension.
• Post-production editing.
• Conferencing camera extension.
• Remote storage.

Product Specifications

Range
• OM2 Multimode Fiber: Up to 50m (165 ft).
• OM3 Multimode Fiber: Up to 100m (330 ft).

Speeds
• USB 3.0: Up to 5Gbps (Not backward compatible with USB 2.0/1.1)

LEX
• USB Connector: 1 x USB 3.0 Type B Locking Receptacle
per AIA USB3 Vision™ specification.
• Link Connector: 1 x Duplex LC Connector.
• Dimensions: 100mm x 76mm x 26mm (3.94" x 2.99" x 1.02").
• Enclosure Material: Anodized Aluminum.

REX
• USB Connectors: 2 x USB 3.0 Type A Locking Receptacles
per AIA USB3 Vision™ specification.
• Link Connector: 1 x Duplex LC Connector.
• Dimensions: 100mm x 76mm x 26mm (3.94" x 2.99" x 1.02").
• Enclosure Material: Anodized Aluminum.
• Power Connector: 24V DC, 1A, Locking, 2.5 mm, center-positive.
• Available Current: 900mA for each USB Port.
• Power Supply: 100-240V AC Brick, Locking.

Environmental
• Operating Temperature: 0°C to 50°C (32°F to 122°F).
• Storage Temperature: -20°C to 70°C (-4°F to 158°F).
• Operating Humidity: 20% to 80% relative humidity, non-condensing.
• Storage Humidity: 10% to 90% relative humidity, non-condensing.

Compliance
• EMC: FCC (Class B), CE (Class B).
• Environmental: RoHS2 (CE).
• Machine Vision: Works with AIA USB3 Vision™ compliant devices.

Support
• Warranty: 2-year.
