CYP PUV-2606RX

The PUV-2606RX HDBaseT2 Receiver is the standard RX within the reverse PoH (RX powers TX) PUV-2600 series, it offers a simple solution for receiving uncompressed HD audio and video, as well as Ethernet and control, via a single run of Cat.6/7 cable over distances of up to 100 meters.

Multiple data and control signal types are supported, including USB 2.0, IR, RS-232 and LAN connections. An independent balanced analogue stereo audio output is also provided to easily de-embed the extended stereo audio signal. The HDBaseT input supports receiving resolutions up to a maximum of 4K@30Hz (4:4:4, 8-bit) or 4K@60Hz (4:2:0, 8-bit) from a compatible HDBaseT Transmitter.

When paired with the standard PUV-2608TX or the more advanced EL-2600V, the PUV-2606RX has switchable USB 2.0 host (Type B) connections available (1 for the remote TX, 1 for the RX) which can connect to devices on up to 6 USB 2.0 (Type A) ports (3 on the TX, 3 on this RX) forming a highly flexible KVM extension configuration (Note: Only 1 USB host may be active at a time).

The PUV-2606RX (PSE) can provide PoH (Power over HDBaseT) power to the connected PUV-2600 series HDBaseT Transmitter (PD) (compatible TX's only), allowing for greater flexibility within different installation scenarios. USB host selection is controlled via a front panel button.

• HDMI 2.0 and DVI 1.0 compatible
• HDCP 2.2 and HDCP 1.x compliant
• HDBaseT 2.0 compatible
• 1 HDBaseT input and 1 HDMI output
• 3 USB 2.0 Type A ports and 1 USB 2.0 Type B port
• Supports HDBaseT input resolutions up to 4K@60Hz (4:2:0, 8-bit)
• HDMI output supports resolutions up to 4K@60Hz (4:2:0, 8-bit)
• HDBaseT input receives video, audio, and data over a single Cat.5e/6/7 cable and can reach distances up to 100m/230ft at 4K when using Cat.6a/7
• HDBaseT feature support: HD Video and Audio, 100BaseT Ethernet, PoH (PSE), and control (bi-directional IR/RS-232/USB 2.0)
• Supports CEC bypass
• Supports pass-through of audio formats including LPCM (up to 8 channels), Bitstream and HD Bitstream from HDMI sources
• Reception of independent analogue stereo audio extension
• Flexible USB host selection using the front panel button: Note: Multiple USB hosts may be connected at once (up to 2 total, between the Tx and a compatible Rx unit) with a single selected host active at a time
• Supports local power, or power via PoH from Receiver (PSE) to Transmitter (PD) (compatible Receivers only)
• Controllable via a front panel button
