CYP PUV-1610TX
|
Qty. | Login to see stock. | Login to buy |
​The PUV-1610TX Transmitter enables transmission of video resolutions up to 4K UHD, along with HD audio, 2-Way IR, RS-232, PoH (Power over HDBaseT), and LAN signals up to 100m. This solution provides advanced signal management ensuring reliable results in the most demanding installation environments. All audio, video, control, and power are transmitted simultaneously over a single CAT6a/7 cable up to 100m.
A key feature of the PUV-1600 series is that the power is sent to the TX from the mains powered RX. This offers additional flexibility when integrating and designing commercial AV systems.
• Supports uncompressed video/audio up to 10.2Gbps
• HDCP2.2 Compliant
• Supports resolutions VGA~WUXGA, 480i~1080p, 4K UHD@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2), 4K UHD@ 60Hz (YUV 4:2:0), 4K/2K@24/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/2K@ 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings
• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7
• 1080p signals can be transmitted up to 100m via CAT5e/6/6a/7
• Audio support up to 7.1CH & Dolby TrueHD, DTS-HD
• 5-Play™ convergence: HDMI, LAN, POE & Control (IR & RS232)
• Supports 3D signals
• PoH received from the mains powered RX
